凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (35.550.02) - TAILGATE LIFT HYDRAULIC CYLINDER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
371 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87517397
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 373.38mm Stroke
|
PA
Tailgate Lift
|
| 2. |
87025720
|
[1] |
HEAD
|
PA
Cylinder
|
| 3. |
529340
|
[1] |
SEAL,31.75mm ID x 43.05mm OD x 4.76mm Thk
|
NH
Rod Wiper
|
| 4. |
86513307
|
[1] |
SEAL,31.75mm ID x 37.85mm OD x 6.35mm Thk
|
NH
Double-Lip, 1.50" OD x 1.25" ID x .250" Tk.
|
| 5. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Cylinder
|
| 6. |
86553483
|
[1] |
SEAL
|
NH
Piston, 3 Piece
|
| 7. |
270103
|
[1] |
BACK-UP RING,45.01mm ID x 51mm OD x 1.27mm Thk
|
NH
Backup, 1.772" ID x .043" Thk
|
| 8. |
510120
|
[1] |
O-RING,0.139" Thk x 1.734" ID, -224, Cl 5, 75 Duro
|
GI
|
| 9. |
87025722
|
[1] |
PISTON ROD
|
PA
|
| 10. |
87025721
|
[1] |
PISTON
|
PA
Superseded by part number: 47583103
|
| 11. |
280724
|
[1] |
LOCK NUT,3/4" - 16
|
NH
|
| 12. |
87025441
|
[1] |
SEAL KIT
|
PA
Kit
|
