纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (5.601[01]) - HOODS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
888 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76089051 | [1] | GRILLE | LEC- UPPER |
| 2. | 76093360 | [1] | PANEL | LEC- UPPER LEFT |
| 2. | 76093361 | [1] | PANEL | LEC- UPPER RIGHT |
| 3. | 76041613 | [2] | LOCK | LEC- ASSY SEE PAG. 5 |
| 4. | 76030113 | [2] | HANDLE | LEC |
| 5. | 10615479 | [8] | LOCK WASHER,6.4mm ID x 11mm OD x 0.7mm Thk | LEC Superseded by part number: |
| 6. | 10725921 | [8] | THIN NUT,Thin, M6 x 1, Cl 05 | LEC Superseded by part number: |
| 7. | 76054537 | [2] | GAS STRUT | LEC |
| 8. | 16044031 | [4] | BOLT,Hex, M8 x 1.25 x 40mm, Cl 10.9 | LEC Superseded by part number: 9780069 |
| 9. | 76046965 | [4] | PIN | LEC |
| 10. | 10796401 | [4] | COTTER PIN,M3.2 x 18 | TTF Superseded by part number: |
| 11. | 12638631 | [4] | WASHER,10.6mm ID x 18mm OD x 2mm Thk | LEC Superseded by part number: 86625251 |
| 12. | 76092054 | [2] | BRACKET | LEC |
| 13. | 79092929 | [1] | PIN,12mm OD x 80mm L | LEC |
| 14. | 12577521 | [2] | NUT,M12 x 1.75 | LEC |
| 15. | 12648531 | [2] | WASHER,12.2mm ID x 28mm OD x 4mm Thk | LEC Superseded by part number: 86625256 |
| 16. | 16043631 | [6] | SCREW,Hex, M8 x 25mm, Cl 10.9, Full Thd | BHB Superseded by part number: 43234 |
| 17. | 12645031 | [6] | WASHER,8.45mm ID x 21mm OD x 3mm Thk | LEC |
| 18. | 14496531 | [4] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 20. | 16100821 | [4] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 27. | 76089052 | [1] | GRILLE | LEC- LOWER |
| 31. | 11112031 | [10] | SCREW,Hex, M12 x 18mm, Cl 10.9, Full Thd | LEC |
| 32. | 79035385 | [2] | PIN | LEC Superseded by part number: 87617620 |
| 33. | 10798101 | [2] | COTTER PIN,M6.3 x 25 | TTF6,3X25 Superseded by part number: 10796901 |
| 34. | 87332128 | [1] | | |
