卡特零件查询（725） 170-4734: MOTOR GP-GEAR
广数供应链运营团队, 14 02月, 2025，浏览：
301 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 1B-8714 | [1] | KEY-WOODRUFF | |
| 2. | 8T-0341M | [2] | BOLT-SOCKET HEAD(M10X1.5X60-MM) | |
| 3. | 201-2693 | [1] | VALVE-THERMOSTAT(HYDRAULIC FAN MOTOR) | |
| 4. | 201-2692Y | [1] | MOTOR GP-GEAR(HYDRAULIC FAN) | |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 201-2695 | [1] | KIT-SEAL(HYDRAULIC FAN MOTOR) | |
| | | | (INCLUDES SNAP RING, SCREEN, BONDED SEALS, O-RING SEALS, SHAFT SEAL, WASHERS, BACKUP SEALS, PRESSURE BALANCE SEALS |
| | | | & O-RINGS) |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
