纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (3.434[05]) - HYDRAULIC SYSTEM PIPING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
278 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76075443 | [1] | FLEXIBLE HOSE | LEC- REAR |
| 2. | 76075442 | [1] | FLEXIBLE HOSE | LEC- FRONT |
| 3. | 76076767 | [1] | FLEXIBLE HOSE | LEC |
| 4. | 79054440 | [1] | HYD CONNECTOR | LEC12 A 45° |
| 5. | 79112066 | [1] | HYD CONNECTOR | LEC |
| 6. | 76089156 | [1] | FLEXIBLE HOSE | LEC |
| 7. | 71418893 | [4] | CLAMP | LEC3/4" Superseded by part number: 727077 |
| 8. | 76036879 | [4] | ELBOW | LEC |
| 9. | 14463281 | [2] | O-RING,0.984" ID x 0.139" Width | TTF |
| 10. | 14420231 | [2] | HEX SOC SCREW,M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC |
| 10. | 14421431 | [6] | HEX SOC SCREW,M10 x 1.5 x 100mm, Cl 10.9 | LEC |
