纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.467[04]) - PUSHBEAMS AND STRUTS (HSU) - CYLINDER - OPTIONAL CODE 774186021 - VERSION (04) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
396 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76066215 | [1] | FLEXIBLE HOSE | LEC |
| 2. | 76066216 | [1] | FLEXIBLE HOSE | LEC |
| 3. | 79100437 | [2] | FLANGE | LEC Superseded by part number: 9992298, 79113056 |
| 4. | 70924110 | [2] | O-RING | LEC3,53X24,99 Superseded by part number: 98458442 |
| 5. | 14420331 | [10] | HEX SOC SCREW,M10 x 1.5 x 35mm, Cl 10.9, Full Thd | LEC |
| 6. | 70923841 | [2] | O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro | LEC Superseded by part number: 9992298 |
