纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.480[01]) - FRONT IMPLEMENT ALL HYDR.- MOLDBOARD PAT 7/8R - OPTIONAL CODE 774182021 - VERSION (01-02) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
170 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76093768 | [1] | DOZER BLADE | LEC- ASSY |
| 2. | 76089287 | [1] | CUTTING EDGE | LEC- RIGHT Superseded by part number: 76072410 |
| 3. | 76089288 | [1] | CUTTING EDGE | LEC- LEFT Superseded by part number: 76072411 |
| 5. | 8282270 | [6] | PLOW BOLT,Plow, M20 x 1.5 x 67mm, Cl 10.9 | LEC |
| 6. | 86015195 | [22] | NUT,M20 x 1.5, Cl 10 | RAC |
| 7. | 14497131 | [22] | WASHER,21mm ID x 37mm OD x 3mm Thk | LEC Superseded by part number: 140021 |
| 8. | 627-16045 | [8] | BOLT,Hex, M16 x 2 x 45mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86508624 |
| 9. | 79005240 | [8] | WASHER,16.8mm ID x 36mm OD x 8mm Thk | LEC16X35X8 |
| 10. | 76089286 | [2] | CUTTING EDGE | LEC- CENTRAL Superseded by part number: 79101015 |
| 11. | 8273211 | [16] | PLOW BOLT,Plow, M20 x 1.5 x 62mm, Cl 10.9 | LEC |
