| 1. | 84540646 | [1] | FRAME | BURUpper |
| 2. | 84382952 | [1] | SEALING STRIP,25mm W x 540mm L x 12mm Thk | BURFoam, Adhesive |
| 3. | 86512424 | [10] | CARRIAGE BOLT,Sq Nk, M10 x 30mm, Cl 8.8, Full Thd | NH Superseded by part number: 86512446 |
| 4. | 9671714 | [22] | FLANGE BOLT,Hex, M8 x 1.25 x 25mm, CL 8.8 | NH |
| 5. | 84540635 | [1] | FRAME | BURCac Mount |
| 6. | 84382949 | [2] | SEALING STRIP,12mm W x 500mm L x 12mm Thk | BURFoam |
| 7. | 84382950 | [2] | SEALING STRIP,12mm W x 420mm L x 6mm Thk | BURFoam |
| 8. | 9804260 | [4] | BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8 | NH |
| 9. | 84316339 | [4] | HUB,10mm ID x 23mm OD x 10.8mm L | FARCollar, Sliding |
| 10. | 87655046 | [4] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BURM10 x 10.65 x 23.0 x 2.2 Hts Boron |
| 11. | 87655042 | [7] | SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk | BURM8 x 8.80 x 17.5 x 2.2 Hts Boron |
| 12. | 16043221 | [8] | BOLT,Hex, M8 x 16mm, Cl 8.8, Full Thd | HFI Superseded by part number: 16043224 |
| 13. | 87700737 | [4] | CLIP | RACPin |
| 14. | 84269372 | [4] | PIN,9.65mm OD x 177.75mm L | FARCooling Package, Radiator |
| 15. | 825-1408 | [7] | NUT,M8, Cl 8 | CAS Superseded by part number: 43362 |
| 16. | 84542663 | [1] | SUPPORT | BURRear |
| 17. | 84382953 | [2] | SEAL | BURFoam Superseded by part number: 47426880 |
| 18. | 47376041 | [1] | FRAME | BURLower |
| 19. | 87036956 | [2] | WASHER,32.8mm ID x 66.5mm OD x 6mm Thk | FAR |
| 21. | 13507701 | [4] | WASHER,16.4mm ID x 27mm OD x 2mm Thk | BAS |
| 22. | 84557202 | [1] | RUBBER WEATHERSTRIP | BURSeal, Bulb |
| 23. | 84591203 | [1] | BAFFLE | BURLower Superseded by part number: 47764487 |
| 24. | 120112 | [2] | BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd | NH |
| 25. | 84591196 | [1] | BRACKET | BURDeaeration Bottle |
| 26. | 8475948 | [2] | NUT,M10 x 1.5, Cl 8 | BER Superseded by part number: 100037 |
| 27. | 84592707 | [1] | BAFFLE | BURMiddle |
| 28. | 84540649 | [2] | ISOLATOR,50mm OD x 50mm L | BURVibration |
| 29. | 86625245 | [8] | WASHER,0.52" ID x 2" OD x 0.16" Thk | IMO0.521 x 2 x 0.16 Hts |
