神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (03-003) - GOVERNOR (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
873 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CZ-KS06 | [1] | GOVERNOR(INNER PARTS)(M1) | |
| . . | 6D221CZ-KS09 | [1] | GOVERNOR(INNER PARTS)(M1) | |
| . . | 6D221CZ-KS07 | [1] | GOVERNOR(INNER PARTS)(M1) | |
| . . | 6D221CZ-KS04 | [1] | GOVERNOR(INNER PARTS)(M1) | |
| . . | 6D221CZ-KS01 | [1] | GOVERNOR(INNER PARTS)(M1) | |
| . . | 6D221CT-KS03 | [1] | GOVERNOR(INNER PARTS)(M1) | |
| . . | 6D221CZ-KS0A | [1] | GOVERNOR(INNER PARTS)(M1) | |
| 1-336. | VAME059656 | [1] | GOVERNOR | KOBRSV TYPE |
| 1. | VA54000700 | [1] | HOUSING, GOV | |
| 3. | VA29632507 | [1] | O-RING | |
| 4. | VA54007290 | [1] | PLUG | |
| 6. | VA54007020 | [1] | ADAPTER | |
| 7. | VA20018184 | [1] | BOLT | |
| 9. | VA54350190 | [1] | PLATE | |
| 10. | VA20006144 | [6] | BOLT | BOLT |
| 12. | VA54010110 | [1] | SCREW | |
| 13. | VA54011010 | [2] | NUT, LOCK | |
| 35. | VA54500332 | [1] | COVER, GOV | |
| 35B. | VA54321040 | [1] | BUSHING | |
| 38. | VA54031240 | [1] | SCREW | |
| 39. | VA29240601 | [1] | NUT | |
| 47. | VA54036030 | [2] | PLUG | |
| 51. | VA20106504 | [2] | BOLT | |
| 53. | VA54010010 | [1] | SCREW | |
| 56. | VA201063S4 | [4] | BOLT | |
| 65. | VA55404370 | [1] | CAP | |
| 80. | VA54063140 | [1] | COVER | |
| 82. | VA29020621 | [2] | BOLT | |
| 63. | VA20006164 | [2] | BOLT | |
| 100. | VA54101052 | [1] | FLYWEIGHT ASSY | |
| 101. | VA25803161 | [1] | KEY, WOODRUFF | |
| 102. | VA29321202 | [1] | WASHER, SPG | |
| 103. | VA29231203 | [1] | NUT | |
| 117. | VA54123012 | [1] | SLEEVE ASSY | |
| 118. | VA29311001 | [1] | SHIM, T=0.20 | |
| . . | VA29311018 | [1] | SHIM, T=0.30 | |
| . . | VA29311019 | [1] | SHIM, T=0.40 | |
| . . | VA29311021 | [1] | SHIM, T=1.00 | |
| . . | VA39410000 | [1] | SHIM, T=0 .50 | |
| . . | VA39410010 | [1] | SHIM, T=1.50 | |
| 130. | VA54150040 | [1] | SPRING GOV | SPRING GOV |
| 132. | VA54154040 | [1] | SPRING | SPRING |
| 135. | VA54158102 | [1] | CAPSULE, SPG | |
| 136. | VA54011170 | [1] | NUT | |
| 137. | VA26512154 | [2] | GASKET | GASKET |
| 138. | VA54159120 | [1] | NUT, CAP | |
| 140. | VA54177072 | [1] | CAPSULE, SPG | |
| 141. | VA29201601 | [1] | NUT | |
| 142. | VA54242042 | [1] | CAPSULE, SPG | |
| 143. | VA29201615 | [1] | NUT | |
| 144. | VA26516204 | [2] | GASKET | |
| 145. | VA54159110 | [1] | NUT, CAP | |
| 150. | VA54200012 | [1] | LEVER, SWIVEL | |
| 151. | VA54204190 | [2] | BUSHING | |
| 152. | VA29631802 | [2] | O-RING | |
| 153. | VA16010164 | [2] | RING, SNAP | |
| 154. | VA39611000 | [1] | OILSEAL | |
| 155. | VA39411000 | [2] | SHIM | |
| 156. | VA29311109 | [1] | SHIM, T=0.30 | |
| 157. | VA29141701 | [1] | PLUG | |
| 159. | VA25803131 | [1] | KEY, WOODRUFF | |
| 160. | VA54206280 | [1] | COLLAR | |
| 161. | VA54206020 | [1] | WASHER | |
| 162. | VA29331024 | [1] | GASKET | |
| 163. | VA54401270 | [1] | BOLT | |
| 164. | VA54243022 | [1] | LEVER | |
| 165. | VA54327190 | [1] | SPRING | |
| 166. | VA16010071 | [1] | RING, SNAP | |
| 167. | VA29310802 | [1] | WASHER | |
| 170. | VA54210742 | [1] | GUIDE LEVER ASSY | |
| 174. | VA54230392 | [1] | LINK | |
| 175. | VA16010054 | [1] | RING, SNAP | |
| 181. | VA54236322 | [1] | LEVER, TENSION | |
| 182. | VA54237010 | [1] | PIN | |
| 190. | VA54340012 | [1] | LEVER, CONTROL | |
| 191. | VA54364342 | [1] | IEVER, STOP | |
| 192. | VA20006454 | [1] | BOLT | |
| 201. | VA29631003 | [1] | O-RING | |
| 203. | VA54322010 | [1] | CAP | |
| 207. | VA54326512 | [1] | LEVER ASSY | |
| 208. | VA54327730 | [1] | SPRING | |
| 211. | VA29311052 | [1] | SHIM, T=0.20 | |
| . . | VA29311053 | [1] | SHIM, T=0.25 | |
| . . | VA29311054 | [1] | SHIM, T=0.30 | |
| . . | VA29311055 | [1] | SHIM, T=0.35 | |
| . . | VA29311056 | [1] | SHIM, T=0.40 | |
| . . | VA29311057 | [1] | SHIM, T=0.50 | |
| 236. | VA54352360 | [1] | GASKET | |
| 237. | VA543507S0 | [1] | GASKET | |
| 238. | VA29635202 | [1] | O-RING | |
| 335. | VA26506104 | [2] | GASKET | |
| 336. | VA54035160 | [1] | NUT, CAP | |
