| 1. |
84024465
|
[1] |
COVER
|
POL
|
| 2. |
84550394
|
[1] |
BEARING HOUSING
|
PLO
RH, Incl 34, 35
|
| 3. |
87024498
|
[2] |
PLUG
|
PA
|
| 4. |
86611171
|
[1] |
SPACER
|
NH
Superseded by part number: 87646887
|
| 5. |
67517
|
[3] |
WASHER
|
NH
Superseded by part number: 87016189
|
| 6. |
87646852
|
[1] |
GEAR
|
PLO
23T
|
| 7. |
721
|
[3] |
WASHER,13.5mm ID x 22.2mm OD x 1.36mm Thk
|
NH
Superseded by part number: 86622500
|
| 8. |
128784
|
[1] |
WASHER
|
PA
Superseded by part number: 86629511
|
| 9. |
9670288
|
[1] |
BOLT,Hex, M12 x 35mm, Cl 8.8
|
PA
|
| 10. |
86608142
|
[1] |
PIVOT PLATE
|
NH
Superseded by part number: 87646851
|
| 11. |
86976035
|
[1] |
WASHER
|
NH
|
| 13. |
321204
|
[1] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 14. |
790472
|
[2] |
WASHER,10.3mm ID x 63.5mm OD x 4.8mm Thk
|
FOR
Superseded by part number: 80790472
|
| 15. |
9804262
|
[9] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 16. |
120041
|
[1] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 17. |
9804278
|
[5] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 18. |
412710
|
[3] |
HEX SOC SCREW,Flat Hd, Csk, M6 x 20mm, Cl 10.9
|
NH
Superseded by part number: 14441431
|
| 19. |
86634127
|
[1] |
DISC
|
PA
|
| 20. |
84298456
|
[1] |
BEARING HOUSING
|
PLO
LH
|
| 21. |
87034503
|
[2] |
ARM
|
PA
LH
|
| 22. |
87025127
|
[1] |
WASHER
|
PA
|
| 23. |
9804260
|
[3] |
BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8
|
NH
|
| 24. |
86512446
|
[4] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 25. |
320772
|
[4] |
HEX SOC SCREW,CSS, M10 x 30mm, Cl 8.8
|
ZED
|
| 26. |
84041522
|
[1] |
SPRING,8.5mm OD x 23.1mm L
|
ZED
|
| 27. |
84471506
|
[2] |
RETAINER
|
PLO
|
| 28. |
84478256
|
[1] |
SPROCKET
|
PLO
& Gear, Incl 32, 33, 39
|
| 29. |
84471490
|
[1] |
SPROCKET
|
PLO
28T, RC80
|
| 30. |
84478889
|
[1] |
PAWL
|
PLO
|
| 31. |
47451493
|
[1] |
PLATE
|
PLO
|
| 32. |
86635027
|
[1] |
TAPERED BEARING,49mm ID x 84mm OD x 48mm W
|
NH
|
| 33. |
84351604
|
[1] |
SPACER,49.3mm ID x 73.9mm OD x 23.3mm L
|
PLO
|
| 34. |
330685
|
[1] |
BALL BEARING,50mm ID x 90mm OD x 23mm W
|
NH
|
| 35. |
370013
|
[1] |
SNAP RING,M90 x 3mm Thk, Internal
|
NH
|
| 36. |
9804268
|
[2] |
BOLT,Hex, M12 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 37. |
9804279
|
[2] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 38. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 39. |
84352338
|
[1] |
BEARING,42mm ID x 78mm OD x 45mm W
|
PLO
|
