神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (01-015) - INLET MANIFOLD ASSY Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
367 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-3. | VA3173021200 | [1] | INLET MANIFOLD ASSY | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONMANIFOLD, INLET |
| 2. | VAMF403805 | [4] | STUD 8X20 | |
| 3. | VAMF403803 | [2] | STUD 8X16 | |
| 5. | VA3133000409 | [6] | GASKET | KOBGASKET, INLET MANIFOLD Superseded by part number: VAME001634 |
| 6. | VAMF140225 | [12] | BOLT | KOBBOLT, FLANGE 8X20 |
| 8. | VAME021976 | [1] | GASKET | KOB |
| 9. | VAMF434104 | [4] | NUT | KOBNUT, FLANGE 8 |
