神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (02-006) - OIL FILTER Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
284 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-11. | VAME004090 | [1] | FILTER | KOBOIL ASSY |
| 1-3. | VA3144012030 | [1] | ELEMENT KIT OIL FILT OIL FILTER ELEMENT KIT | ELEMENT KIT OIL FILT OIL FILTER ELEMENT KIT |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONELEMENT, OIL FILTER |
| 2. | VA3134012600 | [1] | O-RING | KOBGASKET, OIL FILTER |
| 3. | VA3134011700 | [1] | O-RING O-RING, CTR BOLT | O-RING O-RING, CTR BOLT |
| 4. | VA3144012708 | [1] | BOLT | KOBBOLT, CTR |
| 5. | VA3134011040 | [1] | SPRING | KOBSPRING ASSY |
| 6-8. | VA3144013603 | [1] | COVER | KOBOIL FILTER CASE ASSY |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONCASE, OIL FILTER |
| 7. | VA3134014700 | [1] | PLUG DRAIN PLUG, DRAIN | PLUG DRAIN PLUG, DRAIN |
| 8. | VAMF660034 | [1] | SEAL | KOBGASKET 12 |
| 9. | VA3134021904 | [1] | CYLINDER HEAD | KOBHEAD, OIL FILTER |
| 10. | VAME014810 | [1] | HYDRAULIC VALVE | KOBRELIEF ASSY |
| 11. | VA3134014500 | [1] | GASKET | KOBGASKET |
| 15. | VA3134003102 | [1] | GASKET | KOBGASKET |
| 16. | VAMH000707 | [2] | BOLT | KOBBOLT, FLANGE 10X30 |
| 16. | VAMH000715 | [1] | SCREW | KOBBOLT, FLANGE 10X35 Superseded by part number: 133276A1 |
| 18. | VA3134001102 | [1] | ARARM ALARM, OIL BY-PASS | ARARM ALARM, OIL BY-PASS |
| . . | VAMF660066 | [1] | GASKET | KOBGASKET 16 Superseded by part number: VAF420216000 |
