神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (03-002) - INJECTION PUMP (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
658 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-53. | NSS | [1] | NOT SOLD SEPARAT | CONINJECTION PUMP ASSY A TYPE (INNER PARTS) (ME008312) ND 0901004861 |
| 1-2. | 1901102770 | [1] | PUMP HOUSING KIT | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONHOUSING, PUMP |
| 2. | 09490430010 | [3] | BOLT,STUD | |
| 3. | 901501330 | [6] | PUMP ELEMENT SUB ASSY | |
| 4. | 901400021 | [6] | DELIVERY VALVE SUB ASSY | |
| 5. | 901370010 | [6] | GASKET, DELIVERY/V | |
| 6. | 901360200 | [6] | SPRING, DELIVERY/V | |
| 6A. | 901330030 | [6] | STOPPER | |
| 7. | 901310010 | [6] | HOLDER. DELIVERY/V | |
| 8. | 902120010 | [1] | RACK, CONTROL | |
| 9. | 902150010 | [1] | SCREW, RUCK GUIDE | |
| 10. | 901610160 | [6] | SLEEVE, CONTROL | |
| 11. | 901560010 | [6] | PINION, CONTROL | |
| 12. | 901570010 | [6] | SCREW, CLAMP | |
| 13. | 901630010 | [6] | SEAT, UPPER SPG | |
| 14. | 901640090 | [6] | SPRING, PLUNGER | |
| 15. | 901650020 | [6] | SEAT, LOWER SPG | |
| 16-20. | 901700070 | [6] | TAPPET SUB ASSY | |
| 16. | 901760050 | [6] | PIN, ROLLER | |
| 17. | NSS | [6] | NOT SOLD SEPARAT | CONBODY, TAPPET |
| 18. | 901780030 | [6] | BUSHING, ROLLER | |
| 19. | 901810030 | [6] | ROLLER | |
| 20. | 9490700111 | [6] | CIRCLIP | |
| 21. | 901890060 | [6] | PLUG, SCREW | |
| 22. | 901910470 | [1] | CAMSHAFT | |
| 24. | 9491010120 | [2] | BEARING, ROLLER | |
| 25. | 901930030 | [2] | RING, ADJUST | |
| 26. | 902010520 | [1] | COVER, BRG | |
| 27. | 9491800060 | [1] | SCREW, HOLLOW | |
| 29-32. | 902700943 | [1] | COVER SUB ASSY | |
| 29. | 902600132 | [1] | PLATE, COVER | |
| 31. | 902430030 | [2] | WASHER | |
| 32. | 902760020 | [2] | SCREW, SET | |
| 36. | 902300031 | [3] | PLATE, LOCK | |
| 39. | 9491400060 | [1] | O-RING | |
| 39A. | 902060010 | [1] | GASKET | |
| 40. | 903610040 | [1] | BEARING, CTR | |
| 41. | 903660021 | [2] | SCREW, GUIDE | |
| 42. | 9490181030 | [2] | WASHER, PLATE | |
| 43-46. | 902400010 | [1] | AIR BREATHER SUB ASSY | |
| 43. | 902410010 | [1] | WASHER, NIPPLE | |
| 44. | 902420010 | [1] | NIPPLE, AIR BREATHER | |
| 45. | 902430030 | [1] | WASHER, NIPPLE | |
| 46. | 902440010 | [1] | SCREW, AIR BREATHER | |
| 47. | 902510010 | [2] | WASHER | |
| 48. | 9491400380 | [1] | O-RING | |
| 49. | 0901940010 | [1] | SHIM T=0.10 | |
| 49. | 0901940020 | [1] | SHIM T=0.12 | |
| 49. | 0901940030 | [1] | SHIM T=0.14 | |
| 49. | 0901940040 | [1] | SHIM T=0.16 | |
| 49. | 0901940050 | [1] | SHIM T=0.18 | |
| 49. | 0901940060 | [1] | SHIM T=0.50 | |
| 49. | 0901940110 | [1] | SHIM T=0.30 | |
| 49. | 0901940140 | [1] | SHIM T=1.00 | |
| 49. | 901940150 | [1] | SHIM T=1.50 | |
| 50. | 9491800310 | [1] | SCREW | |
| 51. | 902220070 | [2] | WASHER | |
| 52. | 9141806201 | [4] | BOLT, W/WSR | |
| 53. | 903110010 | [1] | SHIM T =0.6 | |
| 53. | 903110020 | [1] | SHIM T=0.7 | |
| 53. | 903110030 | [1] | SHIM T=0.8 | |
| 53. | 903110040 | [1] | SHIM T=0.9 | |
| 53. | 903110050 | [1] | SHIM T=1.0 | |
| 53. | 903110060 | [1] | SHIM T=1.1 | |
| 53. | 903110070 | [1] | SHIM T=1.2 | |
| 53. | 903110080 | [1] | SHIM T=1.3 | |
| 53. | 903110090 | [1] | SHIM T=1.4 | |
| 53. | 903110100 | [1] | SHIM T=0.1 | |
| 53. | 903110110 | [1] | SHIM T=0.2 | |
| 53. | 903110120 | [1] | SHIM T=0.3 | |
| 53. | 903110130 | [1] | SHIM T=0.4 | |
| 53. | 0903I10140 | [1] | SHIM T=0.5 | |
| 53. | 903110150 | [1] | SHIM T=0.15 | |
| 54. | 900180081 | [1] | COVER, CONTROL RACK | |
| 55. | 9491300190 | [1] | KEY, WOODRUFF | |
| 56. | 900120080 | [1] | NUT, TIMER ROUND (ME022426) | |
| 57. | 9490150500 | [1] | WASHER, SPG (ME022144) | |
