纽荷兰零件查询(D180C WT/LGP) - CRAWLER DOZER - TIER 4A (12/13-) (90.160.BY[02]) - CONSOLE, ASSY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
363 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 23323H | [4] | SPACER,1/4" Pipe x 1/2" | IH |
| 2. | 614-6016 | [8] | BOLT,Hex, M6 x 1 x 16mm, Cl 8.8, Full Thd | CAS Superseded by part number: 86508568 |
| 3. | 895-11005 | [4] | WASHER,M5 x 10 x 1 | CAS Superseded by part number: 86625261 |
| 4. | 895-25006 | [8] | WASHER,M6 x 18 x 1.6 | CAS Superseded by part number: 86624182 |
| 5. | 84343762 | [1] | CONSOLE | BUR |
| 6. | 86508566 | [4] | BOLT,Hex, M5 x 30mm, Cl 8.8 | WIN |
| 7. | 87270767 | [1] | THROTTLE | BUR |
| 8. | 87639866 | [1] | CONSOLE | BUR |
| 9. | 895-11010 | [2] | WASHER,11mm ID x 20mm OD x 2mm Thk | CAS Superseded by part number: 14496621 |
| 10. | 614-10020 | [2] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd | CAS Superseded by part number: 43138 |
| 11. | 87729511 | [1] | MOUNTING CLIP | BUR |
