凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (028) - PICKUP AND CAM ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
485 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700114144
|
[23] |
GUARD
|
L
WRAPPER - tine
|
| 2. |
77032
|
[1] |
FITTING
|
CAS
1/4-28 ZERK Superseded by part number: 88775
|
| 3. |
700114136
|
[1] |
DEFLECTOR
|
HFI
- right
|
| 4. |
700114172
|
[1] |
TUBE,38.1 mm OD, 102 mm Length
|
CAS
BUSHING - pivot
|
| 5. |
700116125
|
[1] |
HOUSING
|
CAS
CAMTRACK
|
| 6. |
617863R1
|
[2] |
FLANGED BEARING
|
IH
- bearing
|
| 7. |
713834
|
[2] |
BUSHING
|
NNA
- spherical, hex bore Superseded by part number: 700709621
|
| 8. |
378521
|
[1] |
SPACER
|
CAS
BUSHING
|
| 9. |
700114170
|
[1] |
STRAP
|
HFI
- link, pickup
|
| 10. |
700114119
|
[1] |
FRAME
|
HFI
- pickup
|
| . . |
703249
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
702035
|
[3] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 C
|
| . . |
7701758
|
[1] |
BOLT,Hex, 5/8" - 11 x 1 1/2", Gr 5
|
CAS
5/8-11 x 1-1/2 C Superseded by part number: 88062
|
| . . |
7883002
|
[1] |
BOLT,Hex 3/4" - 10 x 5 1/2", Gr 5
|
CAS
3/4-10 x 5-1/2 C Superseded by part number: 86507002
|
| . . |
700013
|
[24] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
7883325
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7703440
|
[23] |
BOLT,Hex Flange, 5/16" - 18 x 5/8"
|
CAS
5/16-18 x 5/8 HFSS Superseded by part number: 271288
|
| . . |
703132
|
[1] |
SERRATED SCREW
|
CAS
5/16-18 x 3/4 HFSS Superseded by part number: 145913
|
