| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 21462745 | [1] | Flange | |
| 2. | 977297 | [6] | Stud | |
| 3. | 865948 | [1] | Gasket | |
| 4. | 941908 | [6] | Spring washer | |
| 5. | 990939 | [1] | Flange nut | |
| 6. | 21484813 | [1] | V-clamp | |
| 7. | 78467377 | [1] | Exhaust pipe clamp | Option |
| 8. | 983048 | [8] | Flange nut |
广数供应链运营团队, 14 02月, 2025，浏览： 306 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 21462745 | [1] | Flange | |
| 2. | 977297 | [6] | Stud | |
| 3. | 865948 | [1] | Gasket | |
| 4. | 941908 | [6] | Spring washer | |
| 5. | 990939 | [1] | Flange nut | |
| 6. | 21484813 | [1] | V-clamp | |
| 7. | 78467377 | [1] | Exhaust pipe clamp | Option |
| 8. | 983048 | [8] | Flange nut |
