凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (060) - MAINFRAME, FRONT, ASSEMBLY AND AXLE ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
762 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T52730
|
[12] |
WHEEL BOLT
|
IH
9/16-18 x 1-1/8 wheel bolt (S.N. CFH0016501 thru CFH0017432) Superseded by part number: 86628557
|
| . . |
826313
|
[12] |
NUT
|
CAS
9/16-18 wheel nut (S.N. CFH0017433 and on) Superseded by part number: G49041
|
| 2. |
700114344
|
[2] |
SCREW
|
CAS
- special
|
| 3. |
300830
|
[2] |
SPACER
|
HFI
|
| 4. |
77057
|
[2] |
|
IH
1/4-28 x 90 deg. ZERK Superseded by part number: 87415, 87415, NLS
|
| 5. |
77040
|
[2] |
FITTING
|
CAS
1/4-28 x 45 deg. ZERK Superseded by part number: 219-90, 219-90, 87569
|
| 6. |
700116214
|
[2] |
SUPPORT
|
HFI
|
| 7. |
700114238
|
[1] |
ARM
|
CAS
SUPPORT - left (Weldment)
|
| 8. |
700114239
|
[1] |
ARM
|
HFI
SUPPORT - right (Weldment)
|
| . . |
702035
|
[7] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 C
|
| . . |
7883374
|
[8] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 HWHMS Superseded by part number: 255918
|
| . . |
7883382
|
[12] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 x 1 HWHMS Superseded by part number: 87034804
|
| . . |
704916
|
[2] |
SLOTTED NUT,5/8"-11, G5
|
CAS
5/8-11 SHN Superseded by part number: 425-1210
|
| . . |
704734
|
[28] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN Superseded by part number: 86521609
|
