凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (064) - SHIELDS, UPPER CENTER, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
657 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700117068
|
[2] |
SUPPORT
|
HFI
|
| 2. |
700117050
|
[1] |
PANEL
|
HFI
- vertical, left
|
| 3. |
7025075
|
[4] |
BRACKET
|
CAS
- hook
|
| 4. |
700116022
|
[1] |
SHIELD
|
HFI
- front, drive shaft
|
| 5. |
700116011
|
[1] |
SHIELD
|
HFI
|
| 6. |
700117057
|
[1] |
PANEL
|
HFI
- right
|
| 7. |
700707437
|
[1] |
COUNTER
|
CAS
- bale
|
| 8. |
700117094
|
[1] |
SHIELD
|
HFI
front, upper
|
| 9. |
763557
|
[4] |
PIN
|
CAS
3/8 x 2-3/4 clevis pin Superseded by part number: Q657
|
| 10. |
700117096
|
[1] |
HINGE
|
CAS
- shield, top Superseded by part number: 700122785, 1703354, 113-52, 700122786
|
| 11. |
700117095
|
[1] |
SHIELD
|
CAS
- top Superseded by part number: 700122786, 1703354, 700122785, 113-52
|
| 12. |
700116216
|
[1] |
SHIELD
|
HFI
- right
|
| 13. |
700116215
|
[1] |
SHIELD
|
HFI
- left
|
| 14. |
700119100
|
[1] |
SHIELD
|
CAS
(S.N. CFH0016839 and on) Superseded by part number: 88542, 86637953, 74740, 700129377, 700129373, 700129372, 700126761, 145458, 121-115, 121-108
|
| 15. |
700709195
|
[1] |
BUMPER
|
CAS
BOARD - chain (S.N. CFH0016839 and on)
|
| . . |
700013
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
7883325
|
[32] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7883374
|
[34] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 HWHMS Superseded by part number: 255918
|
| . . |
700700628
|
[8] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
NO. 10-24 x 1/2 CRPHMS Superseded by part number: 340-1108
|
| . . |
700701069
|
[4] |
SCREW,Cross Pan Hd, 5/16"-18 x 3/4"
|
HFI
5/16-18 x 3/4 CRPHMS Superseded by part number: 86511938
|
