纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (04-14) - HARNESS, CAB/CANOPY (Feb 12 2010 10:46AM) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
318 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 614-5045 | [2] | BOLT,Hex, M5 x 0.8 x 45mm, Cl 8.8, Full Thd | CAS Superseded by part number: 86639027 |
| 2. | 825-1408 | [2] | NUT,M8, Cl 8 | CAS Superseded by part number: 43362 |
| 3. | 83990583 | [6] | LOCK WASHER,M8 x 14.8mm OD x 2.1mm Thk | BRR |
| 4. | 86511826 | [8] | SCREW,Phillips Drive, Pan HD, M5 x 16mm | FOR |
| 5. | 86588450 | [10] | WASHER,6.6mm ID x 12mm OD x 1.6mm Thk | ZED |
| 6. | 86625072 | [4] | NUT | BRR |
| 7. | 86632601 | [4] | LOCK WASHER,8.4mm ID x 15mm OD x 0.8mm Thk | FOR |
| 8. | 86639241 | [2] | NUT,M5 x .8, Cl 8 | FAR |
| 9. | 87327348 | [2] | FUSE,50 Amp | FAR |
| 10. | 87327350 | [2] | FUSE,60 Amp | LEC |
| 11. | 87596056 | [2] | SWITCH | BUR |
| 12. | 87608546 | [1] | CABLE | BUR |
| 13. | 87630150 | [1] | WIRE HARNESS | BUR |
| 14. | 87630667 | [1] | BRACKET, SUPPORTING | BUR |
| 15. | 87638227 | [2] | RELAY | BUR |
| 16. | 87639277 | [1] | WIRE HARNESS | BUR |
| 17. | 87696396 | [5] | RELAY | BUR |
| 18. | 87710105 | [2] | TERMINAL CONNECTOR | BUR |
| 19. | 87710106 | [2] | TERMINAL CONNECTOR | BUR |
| 20. | L11541 | [3] | CABLE TIE,203.2mm L, Nylon | CAS Superseded by part number: 87000312 |
| 21. | 121410A1 | [1] | FUSE,5A, Mini, Tan | CAS Superseded by part number: 10395890 |
| 22. | 121411A1 | [2] | FUSE,7.5A, Mini, Brown | CAS Superseded by part number: 87522595 |
| 23. | 121412A1 | [6] | FUSE,10A, Mini, Red | CAS Superseded by part number: 87522597 |
| 24. | 121413A1 | [4] | FUSE,15A, Mini, Blue | CAS Superseded by part number: 87524877 |
| 25. | 121414A1 | [3] | FUSE,20A, Mini, Yellow | CAS Superseded by part number: 10401190 |
| 26. | 121415A1 | [1] | FUSE,25A, Mini, Clear | CAS Superseded by part number: 10401290 |
| 27. | 121416A1 | [3] | FUSE,30A, Mini, Green | CAS Superseded by part number: 10402190 |
| 28. | 459329C1 | [1] | NUT | IH |
| 29. | 459330C1 | [1] | LOCK WASHER | IH Superseded by part number: 51200012 |
