| 1. |
84568607
|
[1] |
SUPPORT
|
NH
Net
|
| 2. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Net Roll Tube
|
| 3. |
84599675
|
[1] |
ROLL
|
NH
Spreader
|
| 4. |
87643130
|
[2] |
SUPPORT
|
NH
|
| 5. |
86622552
|
[2] |
SHIELD
|
PA
|
| 6. |
27291
|
[2] |
BALL BEARING,20mm ID x 47mm OD x 14mm W
|
NH
Superseded by part number: 84330054
|
| 7. |
84375021
|
[1] |
TUBE
|
PLO
|
| 8. |
47448057
|
[1] |
CURTAIN
|
NH
Superseded by part number: 47917928
|
| 9. |
84408933
|
[1] |
SUPPORT
|
PLO
|
| 10. |
47894638
|
[1] |
SUPPORT
|
NH
|
| 11. |
47447547
|
[1] |
SHAFT
|
NH
|
| 12. |
84569292
|
[1] |
ROLLER
|
PLO
Net Counter
|
| 13. |
88436
|
[1] |
BOLT,Hex, 3/8" - 16 x 2", Gr 5
|
GI
|
| 14. |
84599791
|
[1] |
SUPPORT
|
NH
|
| 15. |
9804264
|
[1] |
FLANGE BOLT,M10 x 50mm, 26mm Thd, Cl 8.8
|
NH
Superseded by part number: 16587625
|
| 16. |
140021
|
[2] |
WASHER,22mm ID x 37mm OD x 3mm Thk
|
NH
|
| 17. |
86516827
|
[1] |
HANDLE
|
NH
|
| 18. |
86509604
|
[1] |
BOLT,Hex Flg, M12 x 75, 8.8
|
WIN
|
| 19. |
87395
|
[2] |
COTTER PIN,1/8" OD x 1-1/4" OAL
|
NH
|
| 20. |
9804278
|
[5] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 21. |
9804265
|
[1] |
FLANGE BOLT,Hex, M10 x 60mm, Cl 8.8
|
NH
|
| 22. |
100037
|
[1] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 23. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 24. |
9804277
|
[10] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 25. |
88206
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 26. |
80664
|
[7] |
WASHER,0.38" ID x 0.88" OD x 0.08" Thk
|
NH
|
| 27. |
86511841
|
[5] |
BOLT,Flng, M8 x 1.25 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 28. |
86050286
|
[1] |
FLANGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 29. |
80702
|
[1] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 30. |
86512446
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 31. |
80577826
|
[2] |
WASHER,8.7mm ID x 34.93mm OD x 1.94mm Thk
|
NH
|
| 32. |
87026611
|
[1] |
SHEET METAL
|
PA
|
| 33. |
87521161
|
[2] |
BUSHING,20.2mm ID x 44.5mm OD x 10.5mm Thk
|
NH
|
| 34. |
87109697
|
[1] |
SPRING
|
GI
|
| 35. |
859896
|
[1] |
SPACER
|
NH
|
| 36. |
9804260
|
[1] |
BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8
|
NH
|
| 37. |
47420685
|
[1] |
SPACER
|
NH
|
| 38. |
47412710
|
[1] |
SHAFT,25.4mm OD x 1774.1mm L
|
NH
|
| 39. |
87010284
|
[2] |
CAMSHAFT BEARING
|
NH
|
| 40. |
80855
|
[2] |
NUT,Hex, 3/8" - 24
|
WIN
|
| 41. |
47412869
|
[1] |
PLATE
|
NH
|
| 42. |
768703
|
[2] |
BUSHING,10.31mm ID x 15.88mm OD x 11.13mm L
|
NH
|
| 43. |
86624176
|
[1] |
WASHER,11mm ID x 20mm OD x 2mm Thk
|
FOR
Superseded by part number: 14496621
|
| 44. |
80722
|
[2] |
LUBE NIPPLE,3/16" x .55" lg, Drive
|
WIN
|
| 45. |
84568730
|
[1] |
LATCH
|
PLO
|
| 46. |
9825943
|
[1] |
SENSOR
|
NH
|
| 47. |
87313
|
[1] |
JAM NUT,Jam, 3/4"-16, G2
|
NH
|
