纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (02-26) - CYLINDER HEAD - VALVE MECHANISM New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
115 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895432 | [5] | SCREW | TORM8 X 1.25 X 70 |
| 2. | 2856458 | [6] | ROCKER ARM | TORRocker Arm Assy, Incl. Ref 3 - 8, 11, 15, 16 Superseded by part number: 2859460 |
| 3. | 4897248 | [2] | RETAINER | TORRetainer Superseded by part number: |
| 4. | 4897245 | [2] | SOCKET | TORSocket Superseded by part number: |
| 4A. | 2856459 | [2] | ROCKER ARM | TORShaft |
| 5. | 4895068 | [1] | ROCKER ARM | TORASSY, Incl. Ref 6 - 8 Superseded by part number: |
| 6. | 4895198 | [1] | NUT,3/8"-24, Heavy | LEC Superseded by part number: |
| 7. | 2830222 | [1] | ADJUSTMENT SCREW,Hdls Hex Skt, 3/8" - 24 x 23.85mm | TOR Superseded by part number: |
| 8. | 4895065 | [1] | SPACER | TOR |
| 9. | 4895421 | [3] | WASHER | TORM6 x 11 x 1.6; Replaces 2852776 |
| 10. | 2852428 | [6] | WIRE CLAMP,6mm ID | TOR Superseded by part number: 504066132 |
| 11. | 4895067 | [1] | ROCKER ARM | TORASSY, Incl. Ref 6 - 8 Superseded by part number: |
| 12. | 4899245 | [5] | SLEEVE | TOR |
| 13. | 4899257 | [1] | HOUSING | TORHOUSING Assy; Rocker Lever; Incl. Ref 12 |
| 14. | 2852427 | [3] | WIRE HARNESS | TOR Superseded by part number: 47401109 |
| 15. | 4899083 | [2] | SCREW | LECFlange |
| 16. | 4893487 | [1] | LEVER | TOR Superseded by part number: |
| 17. | 4895031 | [12] | PUSH ROD | TOR |
| 18. | 2854530 | [12] | BRIDGE | SMCrosshead Valve |
| 19. | 2853788 | [1] | GASKET,10.35mm Thk | TOR Superseded by part number: 504070040 |
| 20. | 2852602 | [3] | HEX SOC SCREW,M6 x 16mm | SMSocket, M6 X 16 Superseded by part number: 16689121 |
| 21. | 4899089 | [2] | SCREW,Hex Flg, M8 x 1.25 x 50 | TOR |
