神钢零件查询(NE6(T)04) - NISSAN DIESEL ENGINE (1/86-12/98) (08-009) - MOTOR STARTING (INNER PARTS) "SAWAFUJI MAKE" Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
675 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-4. | VG2330096076 | [1] | STARTER MOTOR | KOBMOTOR-STARING |
| 2. | VG2330699202 | [2] | COIL | KOBCOIL ASSY-FIELD |
| 3-6. | VG2333799112 | [1] | U-BRACKET | KOBBRACKET ASSY-REAR |
| 3-5. | VG2333099107 | [1] | HOLDER, INJECTOR NOZ | KOBHOLDER ASSY-BRUSH |
| 4. | VG2333399011 | [4] | SPRING | KOBSPRING-BRUSH |
| 5. | VG2337999015 | [4] | BRUSH | KOBBRUSH |
| 6. | VG2333799113 | [1] | U-BRACKET | KOBBRACKET-REAR |
| 10-12. | VG2331099117 | [1] | ARMATURE | KOBARMATURE ASSY |
| 11. | VG2338399117 | [1] | BALL BEARING | KOBBEARING-REAR |
| 12. | VG2338399118 | [1] | BALL BEARING | KOBBEARING-FRONT |
| 13. | VG2334099119 | [1] | BOLT | |
| 14. | VG2334099116 | [1] | BOLT BOLT | BOLT BOLT |
| 15. | VG2331899203 | [1] | CASE, STARTER CASE-GEAR | CASE, STARTER CASE-GEAR |
| 16. | VG2334899005 | [1] | SHAFT | KOBSHAFT |
| 17. | VG2332899001 | [1] | SHIM | KOBSHIM |
| 18. | VG2332899002 | [1] | SHIM | |
| 19.2. | VG2331799004 | [1] | U-BRACKET | KOBBRACKET ASSY CENTER |
| 20. | VG2344199017 | [1] | SCREW | KOBBUSH |
| 21. | VG2334499010 | [1] | O-RING | KOBO RING |
| 22. | VG2332299106 | [1] | ARM LEVER ASSY | ARM LEVER ASSY |
| 23. | VG2332399007 | [1] | SCREW | KOBBOLT |
| 24. | VG2330799000 | [1] | PLATE-LOCK | |
| 25. | VG2331399201 | [1] | SET OF PINIONS | KOBCLUTCH ASSY-PINION |
| 26. | VG2336999016 | [1] | STOP | KOBSTOPPER-PINION |
| 27.28. | VG2331899209 | [1] | CASE | KOBCASE ASSY-PINION |
| 28. | VG2331999014 | [1] | BUSHING | KOBBUSH |
| 30. | VG2332399107 | [2] | SCREW | KOBBOLT |
| 31. | VG2330899001 | [1] | SWITCH | KOBSWITCH |
| 32. | VG2332399008 | [2] | BOLT | |
| 33. | VG2332899003 | [1] | SHIM | |
| 34. | VG2334199010 | [1] | COVER | KOBCOVER Superseded by part number: VG2334199109 |
| 35. | VG2334799012 | [1] | BAR | KOBBAR-CONNECT |
| 36. | VG2330999000 | [2] | CAP | KOBCAP |
| 37. | VG2334499011 | [1] | O-RING | KOBO RING |
| 38. | VG2334299004 | [1] | PACKING | KOBPACKING |
| 39. | VG2334499108 | [1] | OIL SEAL | KOBSEAL-OIL |
| 40. | VG2334499101 | [1] | O-RING | KOBO RING |
