纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (06-11) - HYDROSTATIC MOTOR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
645 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87313556 | [2] | HYDROSTATIC MOTOR | BURHydrostatic Motor, 140cc; Includes Parts On This Figure; Also Includes Parts On Figure 06-10 |
| 2. | 87441440 | [1] | SEAL | BUR |
| 3. | 87441439 | [2] | SEAL | BUR |
| 4. | 87441437 | [1] | SEAL | BUR |
| 5. | 87516658 | [1] | VALVE | BURFlushing Valve Assembly |
| 7. | 238-8011 | [6] | O-RING,0.07" Thk x 0.301" ID, -11, Cl 8, 90 Duro | CAS Superseded by part number: 87778078, 70933922 |
| 8. | 87441438 | [2] | SEAL | BUR |
| 9. | 87441445 | [2] | SEAL | BUR |
| 10. | 864-12025 | [1] | HEX SOC SCREW,M12 x 25mm, Cl 8.8 | CAS Superseded by part number: 87016466 |
| 11. | 87516679 | [1] | ORIFICE | BURFlushing Orifice |
| 12. | 87516678 | [1] | RING | BUROrifice Retaining Ring Superseded by part number: 87528596 |
| 13. | 87516660 | [1] | PISTON | BURPositioning Piston |
| 14. | 87516661 | [1] | PISTON | BURPiston |
| 15. | 87516662 | [2] | BACK-UP RING | BURRING, BACK-UP Backup Ring Superseded by part number: 6915579 |
| 16. | 87516663 | [2] | PIN | BURCylinder Pin |
| 17. | 87516683 | [8] | HEX SOC SCREW,M12 x 35mm, Cl 8.8 | BURM12 x 34 Socket Head Screw |
| 26. | 87713168 | [2] | PIN | BHBPIN, Cylinder |
| 27. | 87713167 | [1] | SCREW | BHBSCREW, Socket Head |
| 28. | 87713164 | [1] | Flushing Valve Assy. | |
| 29. | 87713166 | [1] | PISTON | |
| 30. | 87713165 | [1] | PISTON | BHBPISTON, Positioning |
| 31. | 87713163 | [1] | Control Assy. | |
| . . | 87516671 | [4] | HEX SOC SCREW,M8 x 45mm, Cl 8.8 | BURM8 x 45 Socket Head Screw |
| . . | 87516681 | [2] | HEX SOC SCREW,M6 x 16mm, Cl 8.8 | BURM6 x 16 Socket Head Screw |
| . . | 87516677 | [4] | HEX SOC SCREW,M10 x 55mm, Cl 10.9 | BURM10 x 55 Socket Head Screw |
| . . | 87516682 | [1] | O-RING,17.3mm ID x 2.2mm Width | BUR17.3 x 2.2 |
| . . | 87516672 | [1] | PLUG | BURM14 x 1.5 Plug |
| . . | 87516675 | [2] | PLUG | BUR#60 Plug |
| . . | 87516676 | [1] | PLUG | BUR#60 Plug |
| . . | 87516673 | [1] | PIN | BURM6 x 30 Threaded |
