纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (04-21) - WIPER, FRONT - CAB New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
270 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87397403 | [1] | WIPER ARM | BURFront |
| 2. | 87397404 | [1] | WIPER BLADE | BURFront |
| 3. | 87517858 | [1] | FITTING | BURFiting, Wiper Hose |
| 4. | 87530516 | [1] | ROD WIPER | BURLinkage, Front Wiper |
| 5. | 87530540 | [1] | BRACKET, SUPPORTING | BURBracket, Front Wiper |
| 6. | 87397402 | [1] | WIPER MOTOR | BURFRONT; 24V; For Cab Door Wipers, See Figure 09-26 |
| 7. | 87577777 | [1] | TUBE,6 mm ID x 8 mm OD x 50 mm L | BURTube, Front Wiper |
| 8. | 844-6012 | [2] | BOLT,Hvy Hex, M6 x 12mm, Cl 8.8 | CAS Superseded by part number: 86050272 |
