纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (08-12) - PUMP ASSY, HYDRAULIC GEAR (WITHOUT PTO) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
817 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87604362 | [1] | HYDRAULIC PUMP | BURHydraulic Pump Equipment; W/ Outer Seal Rating Of 125 psi |
| . . | 87604362R | [1] | REMAN-HYD PUMP | BURD150B TIER 3 (HYDRO) (10/07-) |
| . . | 87604362C | [1] | CORE-HYDRAULIC PUMP | BURReturn Number |
| 1. | 107611A1 | [1] | COVER ASSY | CASShaft End, Incl. 1A |
| 1A. | NSS | [2] | NOT SERVICED SEPARATELY | CONBushing, Not Illustrated |
| 2. | L32418 | [1] | SEAL,26.99mm ID x 42.93mm OD x 7.92mm Thk | CAS Superseded by part number: 84489990 |
| 3. | L32320 | [2] | PLUG | CASPLUG, 7/16 NF |
| 4. | A24845 | [1] | OIL SEAL | CASSEAL, OIL |
| 5. | N13580 | [1] | RETAINER | CASRETAINER |
| 6. | 238-5134 | [1] | O-RING,0.103" Thk x 1.862" ID, -134, Cl 5, 75 Duro | CASO-RING Superseded by part number: 374545 |
| 7. | 102-23206 | [1] | SNAP RING,#206, 2.190", Int, Spiral | CASRING, SNAP |
| 8. | 107612A1 | [1] | COVER ASSY | CASCOVER ASSY, Closed End/Port End, Incl. 8A |
| 9. | N13581 | [1] | HOUSING | CASHOUSING, Shaft End |
| 10. | N13582 | [2] | THRUST PLATE | CAS |
| 11. | N13583 | [2] | SEAL | CASSEAL |
| 12. | L32100 | [2] | SEAL,Square, 3.17mm Thk x 101.6mm ID, 70 Duro | CASSEAL |
| 13. | W16323 | [4] | DOWEL | CAS |
| 14. | 107613A1 | [1] | GEAR-SET | CASGEAR-SET, Set Of Two, Shaft End |
| 15. | 19-488 | [4] | WASHER | CASWASHER, 11/16 x 1-11/32 x 3/16 |
| 16. | 13-1084 | [4] | BOLT,Hex, 5/8" - 11 x 5-1/4", Gr 5 | CASBOLT Superseded by part number: 413-1084 |
