纽荷兰零件查询(D150B) - CRAWLER DOZER TIER 3 (HYDRO) (10/07-) (08-23A) - CYLINDER ASSY - TILT - BD New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
549 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 76089486 | [1] | OPERATING CYLINDER | LECAssy., Bulldozer Tilt Incl Ref., 1 - 14 Superseded by part number: 76041029 |
| 1. | 76041930 | [1] | BARREL | LEC |
| 2. | 76041931 | [1] | TIE-ROD | LEC |
| 3. | 76000805 | [1] | SUPPORT | LEC |
| 4. | 76041932 | [1] | CYLINDER HEAD | LEC |
| . . | 76053661 | [1] | SEAL KIT | LECIncl. Refs. 6, 8, 9 ,10, 13 |
| 6. | 79071464 | [1] | SEAL | LECSeals |
| 8. | 76041933 | [1] | RING | LEC Superseded by part number: 76053660, 76053660, 76053661 |
| 9. | 14473280 | [1] | O-RING,0.21" Thk x 4.475" ID, -349, Cl 5, 75 Duro | LEC Superseded by part number: 70923601 |
| 10. | 79023161 | [1] | RING | LEC Superseded by part number: 79076122 |
| 11. | 14420471 | [13] | HEX SOC SCREW,M10 x 1.5 x 40mm, Cl 12.9 | LEC Superseded by part number: 14420474 |
| 12. | 76041934 | [1] | PISTON | LEC |
| 13. | 79099850 | [1] | SET OF PARTS | LEC |
| 15. | 76041935 | [1] | SCREW | LEC |
| 16. | 76041936 | [1] | BALL | LEC |
