| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 76089427 | [1] | OPERATING CYLINDER,Double Acting, 55mm Rod, 509mm Stroke | LECCYLINDER ASSY., Angle; Used on Models with LGP; Incl. Ref. 1 - 17 |
| 1. | 76071175 | [1] | CIRCLIP | LEC |
| 2. | 76071176 | [1] | O-RING | LEC |
| 3. | 76071177 | [1] | WASHER, THRUST | LECWASHER,THRUST |
| 4. | 76071178 | [1] | O-RING | LEC |
| 5. | 76073158 | [1] | BASE PLATE | LEC |
| 6. | 76073159 | [1] | TUBE,Double Acting, 55mm Rod, 509mm Stroke | LEC |
| 7. | 76073160 | [1] | PISTON | LEC |
| 8. | 87352831 | [1] | NUT | LEC |
| 9. | 87352832 | [2] | LOCKING RING | LEC |
| 10. | 87352833 | [1] | BUSHING | LEC |
| 11. | 87352834 | [1] | LOCKING RING | LEC |
| 12. | 76066286 | [1] | LOCKING RING | LEC |
| 13. | 79037239 | [2] | ARTICULATION | LEC |
| 14. | 76066288 | [4] | CIRCLIP | LEC |
| 15. | 76073161 | [1] | ROD | LEC |
| 16. | 76073156 | [1] | SEAL KIT | LECFor Pistons |
| 17. | 76073157 | [1] | SEAL KIT | LECFor Rod |
