| . . | 87651091 | [1] | CYLINDER ASSY.,Double Acting, 50.8mm Rod, 254mm Stroke | BURCYLINDER ASSY., RIPPER, Right Hand, Incl. 1 - 19 |
| . . | 87651091R | [1] | REMAN-HYD CYLINDER | BURD150B TIER 3 (HYDRO) (10/07) |
| . . | 87651091C | [1] | CORE-HYD CYLINDER | BURReturn Number |
| . . | 87651121 | [1] | CYLINDER ASSY.,Double Acting, 50.8mm Rod, 254mm Stroke | BURCYLINDER ASSY., RIPPER, Left Hand, Incl. 1A - 19 |
| . . | 87651121R | [1] | REMAN-HYD CYLINDER | BURD150B TIER 3 (HYDRO) (10/07-) |
| . . | 87651121C | [1] | CORE-HYD CYLINDER | BURReturn Number |
| 1. | 87651092 | [1] | TUBE,101.47 - 108.74 mm ID x 385.1 mm L | BURTUBE, Right Hand, Incl. 2 |
| 1A. | 87651122 | [1] | TUBE,101.47 - 108.74 mm ID x 385.1 mm L | BURTUBE, Left Hand, Incl. 2 |
| 2. | 30613 | [2] | BUSHING,38.33mm ID x 44.45mm OD x 17.6mm L | CASBUSHING |
| 3. | 86642312 | [1] | SELF-TAP SCREW,Hex, #8 - 32 x 3/8" | IMO |
| 4. | 87651094 | [1] | PISTON ROD | BURROD, 50.8 mm (2 in) dia, Incl. 5 |
| 5. | D33047 | [2] | BUSHING,44.68mm ID x 53.98mm OD x 22.23mm L | CASBUSHING |
| 6. | G100438 | [1] | PISTON,100.89mm Bore, 32.8mm Rod, 50.7mm W | CASPISTON |
| 7. | 128135A2 | [1] | GLAND | CASCap Cylinder End |
| . . | 87672315 | [1] | REPAIR KIT | BHBKIT, Seal Repair/Gasket; Incl. 8 - 15 |
| 8. | D95144 | [1] | WIPER SEAL,50.77mm ID x 63.52mm OD x 7.92mm Thk | CAS |
| 9. | G101533 | [1] | WEAR RING,Split, 50.8mm ID x 53.87mm OD x 25.15mm Thk | CAS |
| 10. | 1542876C1 | [1] | SEAL KIT | CASRod and Buffer Seal, Order 1543273C1 |
| 11. | 87016952 | [1] | O-RING,0.139" Thk x 3.609" ID, -239, Cl 5, 75 Duro | RAC |
| 12. | G109299 | [1] | BACK-UP RING,94.87mm ID x 97.67mm OD x 1.4mm Thk | CAS |
| 13. | G102285 | [1] | SEAL,Locking, 98.55mm ID x 102.97mm OD x 6.96mm Thk | CAS |
| 14. | G100440 | [1] | RING,Square, 5.28mm Thk x 88.01mm ID | CAS |
| 15. | G100448 | [2] | RING | CAS |
| 16. | 86982440 | [1] | SPECIAL BOLT | BURWith Washer; 1-1/4 x 2-3/4 |
| 18. | 219-1 | [1] | LUBE NIPPLE,1/8"-27 x .66 lg | CAS Superseded by part number: 80710 |
| 19. | 219-36 | [1] | LUBE NIPPLE,45º, 1/8" NPT x 7/8" lg | CAS Superseded by part number: 80717 |
