凯斯零件查询(RBX341) - CASE IH ROUND BALER (9/02-12/05) (15.06[01]) - ROLL WRAP Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
808 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84024872
|
[1] |
THREADED TIE-ROD
|
PLO
|
| 2. |
86627391
|
[1] |
ARM
|
PLO
|
| 3. |
80322901
|
[1] |
PIN
|
ZED
Superseded by part number: 322901
|
| 4. |
80378244
|
[2] |
LOCK WASHER
|
ZED
10MM Superseded by part number: 378244
|
| 5. |
80130003
|
[1] |
COTTER PIN
|
ZED
3.2x20 Superseded by part number: 130003
|
| 6. |
80370024
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 370024
|
| 7. |
80378247
|
[1] |
WASHER
|
ZED
20MM Superseded by part number: 378247
|
| 8. |
86627392
|
[1] |
LEVER
|
PLO
|
| 9. |
80853488
|
[1] |
SPRING
|
PLO
|
| 10. |
86977775
|
[1] |
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
|
ZED
|
| 11. |
84024821
|
[1] |
BRAKE
|
PLO
|
| 12. |
80395654
|
[1] |
SCREW
|
NH
Superseded by part number: 395654
|
| 13. |
89818115
|
[1] |
SPRING
|
PLO
Superseded by part number: 9818115
|
| 14. |
100016
|
[3] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 15. |
84025025
|
[1] |
BUSHING
|
PLO
|
| 16. |
84024585
|
[2] |
BUSHING,20mm ID x 23mm OD x 15mm Thk
|
PA
|
| 17. |
80120068
|
[1] |
SCREW
|
ZED
M10x40 Superseded by part number: 120068
|
| 18. |
84024749
|
[1] |
SPACER,10.5mm ID x 16mm OD x 8.5mm L
|
PA
|
| 19. |
80100037
|
[1] |
NUT,M10 x 1.5, Class 8
|
ZED
M10 Superseded by part number: 100037
|
