凯斯零件查询(RBX341) - CASE IH ROUND BALER (9/02-12/05) (15.07[01]) - ROLL WRAP Case Agriculture
广数供应链运营团队, 18 02月, 2025，浏览：
140 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84024841
|
[1] |
ROD
|
PLO
|
| 2. |
84025083
|
[1] |
TUBE,16 mm Diameter, 200 mm Length
|
PLO
|
| 3. |
84024807
|
[1] |
SPRING
|
PLO
|
| 4. |
89602976
|
[1] |
YOKE
|
PLO
Superseded by part number: 9602976
|
| 5. |
86627686
|
[1] |
PLATE
|
NH
|
| 6. |
80120111
|
[3] |
SCREW
|
ZED
M10x30 Superseded by part number: 43140
|
| 7. |
80140045
|
[3] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 8. |
100016
|
[5] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 9. |
86627393
|
[1] |
ARM
|
PLO
|
| 10. |
80300869
|
[1] |
LOCK PIN
|
ZED
Superseded by part number: 300869
|
| 11. |
86627390
|
[1] |
SUPPORT
|
PA
Superseded by part number: 87034973
|
| 12. |
84024585
|
[2] |
BUSHING,20mm ID x 23mm OD x 15mm Thk
|
PA
|
| 13. |
84024851
|
[1] |
IDLER LEVER
|
PLO
|
| 14. |
80120115
|
[1] |
SCREW
|
ZED
M10x70 Superseded by part number: 120115
|
| 15. |
84024850
|
[1] |
LEVER
|
PLO
|
| 16. |
80378244
|
[1] |
LOCK WASHER
|
ZED
10MM Superseded by part number: 378244
|
| 17. |
84025086
|
[1] |
CAMSHAFT BEARING
|
PLO
|
| 18. |
80140042
|
[1] |
WASHER
|
ZED
10MM Superseded by part number: 140042
|
