神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (03-001) - HOUSING-AIR INTAKE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
836 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VG1401796003 | [1] | ELBOW | KOBAIR INTAKE |
| 2. | VG1401096002 | [1] | GASKET | KOBINTAKE |
| 3. | VG1106596001 | [1] | HEATER ASSY AIR | HEATER ASSY AIR |
| 4. | VG1480696004 | [2] | GASKET | KOBINTAKE |
| 5. | VG0822902510 | [4] | STUD | KOB |
| 6. | VG0891114010 | [4] | NUT | NUT |
| 8. | VG1400996012 | [1] | DUCT AIR INTAKE (FOR A1) | DUCT AIR INTAKE (FOR A1) |
| 8. | VG1400996077 | [1] | DUCT-AIR INTAKE (FOR A14) | |
| 8. | VG1400996118 | [1] | DUCT-AIR INTAKE (FOR A13) | |
| 9. | VG0822381410 | [1] | STUD (FOR A1) | |
| 10. | VG0115103104 | [4] | SCREW | KOB |
| 11. | VG0891114010 | [4] | NUT | NUT |
| 12. | VG0891514010 | [4] | WASHER SPRING | WASHER SPRING |
| 13. | VG0891544010 | [1] | WASHER PLAIN | WASHER PLAIN |
| 14. | VG1402096000 | [1] | FLEXIBLE HOSE | KOBDUCT |
| 15. | VG2138390115 | [2] | CLAMP | KOB |
