凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (05.23[01]) - BEARING AXLE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
368 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84817113
|
[1] |
AXLE
|
PLO
RH, Serial Range: (3-23) Superseded by part number: 87646601
|
| 2. |
84817112
|
[1] |
AXLE
|
PLO
LH, Serial Range: (3-23) Superseded by part number: 87646599
|
| 3. |
86511325
|
[2] |
WASHER,15mm ID x 28mm OD x 2.5mm Thk
|
PA
|
| 4. |
412685
|
[2] |
COTTER PIN,M4 x 32
|
ZED
|
| 5. |
84800532
|
[2] |
SPRING
|
PLO
|
| 6. |
84800534
|
[2] |
PIN
|
PLO
|
| 7. |
84820535
|
[1] |
AXLE
|
PLO
RH
|
| 8. |
84820536
|
[1] |
AXLE
|
PLO
LH
|
| 9. |
84820537
|
[2] |
BALL BEARING,65mm ID x 120mm OD x 24.75mm W
|
PLO
|
| 10. |
84818048
|
[2] |
ROLLER BEARING
|
PLO
|
| 11. |
84820538
|
[12] |
BOLT
|
PLO
|
| 12. |
84818053
|
[12] |
WHEEL NUT
|
PLO
|
| 13. |
84822532
|
[2] |
RING
|
PLO
|
| 14. |
84818045
|
[2] |
HUB
|
PLO
|
| 15. |
84818049
|
[2] |
NUT
|
PLO
|
| 16. |
84818050
|
[2] |
PIN
|
PLO
|
| 17. |
84818051
|
[2] |
COVER
|
PLO
|
| 18. |
84822533
|
[2] |
LEVER
|
PLO
|
| 19. |
84822534
|
[4] |
BRAKE PACKAGE
|
PLO
|
| 20. |
84822535
|
[2] |
SHAFT
|
PLO
|
| 21. |
84822537
|
[2] |
HUB
|
PLO
|
| 22. |
84820534
|
[2] |
CYLINDER
|
PLO
|
| 23. |
84800533
|
[2] |
PIN
|
PLO
Superseded by part number: 84014240
|
