神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (05-007) - GOVERNOR, (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
632 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-146. | VG1910196574 | [1] | GOVERNOR (FOR A1) | |
| 1-146. | VG1910196576 | [1] | GOVERNOR (FOR A2) | |
| 1. | VG1935699113 | [1] | HOUSING | |
| 2. | VG1927999003 | [1] | O RING | |
| 3. | VG1928999004 | [1] | PLUG | |
| 4. | VG1938099000 | [1] | PLATE | |
| 5. | VG1938299015 | [8] | BOLT | |
| 6. | VG1931090004 | [1] | SCREW | KOB Superseded by part number: 76602442 |
| 7. | VG1926890000 | [2] | NUT | |
| 8.9. | VG1937399014 | [1] | COVER | KOBASSY |
| 9. | VG1912390002 | [1] | SCREW | KOBBUSH Superseded by part number: 76602401 |
| 10. | VG1933699009 | [1] | SCREW | |
| 11. | VG1937090003 | [1] | NUT | |
| 12. | VG1938290001 | [2] | PLUG | |
| 13. | VG1928599000 | [2] | BOLT | |
| 14. | VG1931090003 | [1] | SCREW | |
| 15. | VG1979799001 | [4] | BOLT | |
| 20. | VG1928699019 | [1] | COVER | |
| 21. | VG1979799003 | [2] | BOLT | |
| 22. | VG1938299017 | [2] | BOLT | |
| 23. | VG1931299008 | [1] | WEIGHT | KOBASSY |
| 24. | VG1674237500 | [1] | KEY | |
| 25. | VG1687490001 | [1] | WASHER-SPRING | |
| 26. | VG1932590002 | [1] | NUT | |
| 27.28. | VG1936399007 | [1] | SLEEVE ASSY | |
| 28. | VG1933999000 | [1] | BEARING | |
| 29. | VG1934290001 | [1] | SHIM, T=0.2 | |
| 29. | VG1934290002 | [1] | SHIM, T=0.3 | |
| 29. | VG1934290003 | [1] | SHIN, T=0.4 | |
| 29. | VG1934290004 | [1] | SHIM, T=1.0 | |
| 29. | VG1928399118 | [1] | SHIM, T=0.5 | |
| 29. | VG1928399119 | [1] | SHIM, T=1.5 | |
| 31. | VG1930390003 | [1] | SPRING | KOB |
| 32. | VG1928090001 | [1] | SPRING | KOB(FOR F1) |
| 32. | VG1930399109 | [1] | SPRING (FOR F2) | |
| 33. | VG1937699108 | [1] | CAP | KOBCAPSULE-SPRING (FOR F1) |
| 33. | VG1927499112 | [1] | CAPUSLE-SPRING (FOR F2) | |
| 34. | VG1931499016 | [1] | NUT | KOB Superseded by part number: 76602447 |
| 35. | VG1677899002 | [2] | GASKET | |
| 36. | VG1929099004 | [1] | NUT | KOBCAP Superseded by part number: 76602438 |
| 37. | VG1927290003 | [1] | CAPUSLE-SPRING (FOR F1) | |
| 37. | VG1927499113 | [1] | CAPUSLE-SPRING (FOR F2) | |
| 38. | VG1931490001 | [1] | NUT | |
| 39. | VG1927690002 | [1] | LEVER-SWIVEL | |
| 40. | VG19277Z9001 | [2] | BUSH | |
| 41. | VG1927890000 | [2] | O-RING | KOB Superseded by part number: 76602419 |
| 42. | VG1927990000 | [2] | SNAP RING | KOB Superseded by part number: 76602422 |
| 43. | VG1938899005 | [1] | OIL SEAL | KOB Superseded by part number: 76602479 |
| 44. | VG1928399014 | [1] | SHIM | |
| 45. | VG1928390001 | [1] | SHIM | |
| 46. | VG1937890002 | [1] | PLATE | KOB |
| 47. | VG1934490000 | [1] | KEY | KOB Superseded by part number: 76602465 |
| 48. | VG16854Z9000 | [1] | COLLAR | |
| 49. | VG1685490001 | [1] | WASHER | |
| 50. | VG1935399100 | [1] | LEVER-GUIDE (FOR F1) | |
| 50. | VG1935399000 | [1] | LEVER-GUIDE (FOR F2) | |
| 51. | VG1934699010 | [1] | LINK | |
| 52. | VG1933290001 | [1] | RING-SNAP | |
| 53. | VG1923199002 | [1] | PIN | |
| 54. | VG1932790013 | [1] | SHIM | |
| 55. | VG1932299003 | [1] | PIN-SNAP | |
| 56. | VG1933199104 | [1] | LEVER-TENSION | |
| 57. | VG1935090001 | [1] | PIN | |
| 58. | VG1933499015 | [1] | LEVER | KOB |
| 59. | VG1933299107 | [1] | LEVER (FOR A1) | |
| 59. | VG1933499112 | [1] | LEVER (FOR A2) | |
| 60. | VG1938299017 | [1] | BOLT (FOR A1) | |
| 60. | VG1938299000 | [1] | BOLT (FOR A2) | |
| 61. | VG1675537500 | [1] | WASHER-SPRING (FOR A2) | |
| 62. | VG1927890001 | [1] | O RING | |
| 63. | VG1912490001 | [1] | CAP | |
| 64. | VG1912999004 | [1] | LEVER | |
| 65. | VG1913199000 | [1] | SPRING | KOB Superseded by part number: VG1928199004 |
| 66. | VG19125Z9007 | [1] | SHIM, T=0.2 | |
| 66. | VG19125Z9008 | [1] | SHIM, T=0.25 | |
| 66. | VG19125Z9009 | [1] | SHIM, T=0.3 | |
| 66. | VG19125Z9010 | [1] | SHIM, T=0.35 | |
| 66. | VG19125Z9011 | [1] | SHIM, T=0.4 | |
| 66. | VG19125Z9012 | [1] | SHIM, T=0.5 | |
| 70. | VG1939099000 | [1] | GASKET | GASKET |
| 71. | VG1913699000 | [1] | GASKET | KOB Superseded by part number: 76602414 |
| 72. | VG1979890000 | [1] | O RING | |
| 80. | VG1921137500 | [2] | GASKET | GASKET |
| 81. | VG1929099006 | [1] | CAP-NUT | |
| 101-146. | VG1927599018 | [1] | COMPENSATOR ASSY-BOOST (FOR A1) | |
| 101-146. | VG1927599019 | [1] | COMPENSATOR ASSY-BOOST (FOR A2) | |
| 101. | VG1927099004 | [1] | HOUSING | |
| 102. | VG1926999002 | [1] | SPACER | |
| 103. | VG1936099000 | [2] | SCREW | |
| 104. | VG1938299017 | [1] | BOLT | |
| 105. | VG1928199000 | [1] | BOLT | |
| 106. | VG1926037502 | [3] | WASHER-SPRING | |
| 107. | VG1926799000 | [1] | LEVER | |
| 108. | VG1920499001 | [1] | SHAFT | |
| 109. | VG1926599001 | [1] | ROD-PUSH | |
| 110. | VG1671699005 | [1] | SHIM | |
| 110. | VG1671699006 | [1] | SHIM | |
| 111. | VG1913199104 | [1] | SPRING (FOR A1) | |
| 111. | VG1913199105 | [1] | SPRING (FOR A2) | |
| 112. | VG19332L6000 | [1] | WASHER | |
| 113. | VG1926499000 | [1] | DIAPHRAGM | |
| 114. | VG1926399117 | [1] | SHIM (FOR A1) | |
| 114. | VG1687099011 | [1] | SHIM (FOR A2) | |
| 115. | VG1683299013 | [1] | WASHER | |
| 116. | VG0891120610 | [1] | NUT | KOB |
| 117. | VG1926399000 | [1] | PLATE | |
| 118. | VG1926399001 | [1] | COVER | COVER |
| 119. | VG1938290003 | [2] | BOLT | |
| 120. | VG1938299208 | [1] | BOLT | |
| 121. | VG1938790001 | [1] | NUT | |
| 122. | VG1933699004 | [1] | SCREW | |
| 123. | VG1929090001 | [1] | NUT-CAP | |
| 124. | VG1921137500 | [1] | GASKET | GASKET |
| 125. | VG1922037500 | [1] | PLUG | |
| 126. | VG1677899001 | [2] | GASKET | GASKET |
| 127. | VG1675737500 | [1] | EYE BOLT | EYE BOLT |
| 128. | VG1938299017 | [1] | BOLT | |
| 129. | VG1913299002 | [1] | BOLT | |
| 130. | VG1677899001 | [1] | GASKET | GASKET |
| 131. | VG1938999009 | [1] | GASKET | |
| 132. | VG1938999010 | [1] | GASKET | |
| 133. | VG1926299000 | [1] | LEVER | |
| 134. | VG1920637500 | [1] | BOLT | |
| 135. | VG1936899006 | [1] | SEAL-OIL | |
| 136. | VG1434537501 | [1] | SHIM | |
| 136. | VG1434537502 | [1] | SHIM | |
| 137. | VG1921599000 | [1] | SHIM | |
| 138. | VG1923561500 | [1] | PIN-SPLIT | |
| 139. | VG1937699007 | [1] | SPRING | |
| 140. | VG1925099003 | [1] | LEVER | |
| 141. | VG1682590005 | [1] | WASHER-SPRING | |
| 142. | VG0891110800 | [1] | NUT | NUT |
| 143. | VG1913290000 | [1] | SCREW | |
| 144. | VG1913299001 | [1] | SCREW | |
| 145. | VG1913390000 | [2] | NUT-LOCK | |
| 146. | VG1938999012 | [1] | GASKET | |
