纽荷兰零件查询(DC100) - CRAWLER DOZER (N.A. VERSION) (4/00-) (2.327[03C]) - HYDROSTATIC TRANSMISSION PIPINGS DC100 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
859 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76592899 | [2] | SCREW | MAC Superseded by part number: 16044024 |
| 3. | 76598309 | [1] | LEVER | MACParking Brake |
| 5. | 76590848 | [2] | NUT | MAC Superseded by part number: 15503611 |
| 6. | 76591022 | [3] | HYD CONNECTOR | MAC |
| 7. | 76591023 | [2] | HYD CONNECTOR | MAC |
| 8. | 76591024 | [1] | HYD CONNECTOR | MAC |
| 9. | 76591025 | [1] | HYD CONNECTOR | MAC |
| 10. | 76591026 | [1] | SENSOR | MAC |
| 11. | 76591027 | [1] | HYD CONNECTOR | MAC |
| 12. | 76591028 | [1] | HYD CONNECTOR | MAC |
| 13. | 76591029 | [1] | HYD CONNECTOR | MAC |
| 14. | 76592900 | [2] | HOSE | MAC |
| 16. | 76591032 | [4] | HYD CONNECTOR | MAC |
| 17. | 76591033 | [2] | PLUG | MAC |
| 18. | 76591034 | [2] | GASKET | MAC |
| 19. | 76591035 | [1] | HOSE | MAC |
| 20. | 76591036 | [1] | HOSE | MAC |
| 21. | 76591037 | [1] | HYD CONNECTOR | MAC |
| 22. | 76592901 | [1] | HYD CONNECTOR | MAC |
| 23. | 76605883 | [1] | FLEXIBLE HOSE | MAC |
| 24. | 76605884 | [1] | FLEXIBLE HOSE | MAC |
| 25. | 76591041 | [2] | HYD CONNECTOR | MAC |
| 26. | 76591042 | [1] | HYD CONNECTOR | MAC |
| 27. | 76591043 | [2] | HYD CONNECTOR | MAC |
| 28. | 76591044 | [2] | HYD CONNECTOR | MAC |
| 29. | 76591045 | [1] | HOSE | MAC |
| 30. | 76592902 | [1] | HOSE | MAC |
| 31. | 76590990 | [2] | HYD CONNECTOR | MAC |
| 32. | 76591048 | [1] | HYD CONNECTOR | MAC |
| 33. | 76592903 | [1] | HYD CONNECTOR | MAC |
| 34. | 76598524 | [1] | SPACER | MAC |
| 40. | 76591020 | [1] | DRAINCOCK/TAP SUPPLY | MACParking Brake Valve |
| 41. | 76596047 | [6] | SEAL | MACO-Ring |
| 42. | 76596048 | [4] | SEAL | MACO-Ring |
| 43. | 76596046 | [4] | SEAL | MACO-Ring |
| 44. | 76607966 | [1] | HYD CONNECTOR | MAC |
| 45. | 76598312 | [1] | DRAINCOCK/TAP SUPPLY | MAC |
| 46. | 76598311 | [1] | SPRING | MAC |
| 47. | 76605347 | [1] | KNOB | MAC Superseded by part number: 76591018 |
