神钢零件查询(PE6T04) - NISSAN DIESEL ENGINE - LK900 & LK700A W/TURBO (1/03-12/06) (05-010) - PUMP-FEED, (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
511 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-21. | VG1664096000 | [1] | PUMP ASSY FEED | PUMP ASSY FEED |
| 1. | VG1664899008 | [1] | MOTOR HOUSING | KOB |
| 2. | VG1664537501 | [1] | PISTON | KOBPISTON Superseded by part number: 76602249 |
| 3. | VG1664637500 | [1] | SPRING | KOBPISTON |
| 4. | VG1664737500 | [1] | PLUG | |
| 5. | VG1665737500 | [1] | WASHER GASKET | WASHER GASKET |
| 6. | VG1665799010 | [1] | TAPPET ASSY | |
| 7. | VG1666037500 | [1] | PISTON RING SET | KOB Superseded by part number: 76602260 |
| 10. | VG1665237500 | [2] | VALVE, CHECK | VALVE, CHECK |
| 11. | VG1665337500 | [2] | SPRING | KOB |
| 13. | VG1665937500 | [2] | WASHER | KOBGASKET |
| 16. | VG1666599000 | [1] | PUMP PRIMING | PUMP PRIMING |
| 17. | VG1675399002 | [1] | BOLT-EYE | |
| 18. | VG1675399007 | [1] | BOLT-EYE | |
| 19. | VG1664490000 | [1] | COVER | KOB |
| 20. | VG1666237500 | [4] | GASKET | |
| 21. | VG1666399000 | [1] | PLUG | |
