凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (13.05[01]) - PICK-UP, LIFT SYSTEM Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
144 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
80062275
|
[1] |
NUT
|
ZED
M20 Superseded by part number: 62275
|
| 2. |
84024539
|
[1] |
RING
|
PLO
|
| 3. |
84024940
|
[10] |
CAP WASHER
|
PLO
|
| 4. |
84025111
|
[1] |
CAMSHAFT BEARING
|
PLO
|
| 4. |
84800365
|
[1] |
BUSHING
|
PLO
|
| 5. |
84024401
|
[1] |
LEVER
|
PLO
|
| 5. |
84800386
|
[1] |
LEVER
|
PLO
|
| 6. |
84024658
|
[2] |
WASHER,36mm ID x 60mm OD x 4.42mm Thk
|
PLO
|
| 7. |
80120083
|
[1] |
SCREW
|
ZED
M12x70 Superseded by part number: 9706717
|
| 8. |
80120092
|
[1] |
SCREW,M16 x 70mm
|
ZED
M16x70 Superseded by part number: 120092
|
| 9. |
84024656
|
[1] |
TUBE,34.5 mm Diameter, 700 mm Length
|
PLO
|
| 10. |
89838996
|
[1] |
COTTER PIN
|
ZED
Superseded by part number: 9838996
|
| 12. |
84025108
|
[1] |
SPRING
|
PLO
|
| 13. |
84024657
|
[2] |
BUSHING
|
PLO
|
| 13. |
84800366
|
[2] |
BUSHING
|
PLO
|
| 14. |
80100038
|
[1] |
NUT
|
ZED
M12 Superseded by part number: 100038
|
| 15. |
84025110
|
[1] |
SPRING
|
PLO
|
