凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (13.07[01]) - FEEDER AND CROPCUTTER ASSEMBLY, FRAME Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
857 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84822383
|
[1] |
FRAME
|
PLO
, Serial Range: -C667 Superseded by part number: 84820192
|
| 1. |
84820192
|
[1] |
FRAME
|
PLO
, Start Serial: D668
|
| 1. |
84822352
|
[1] |
FRAME
|
PLO
, Serial Range: -C667 Superseded by part number: 84820596
|
| 1. |
84820596
|
[1] |
FRAME
|
PLO
, Start Serial: D668
|
| 2. |
84024165
|
[1] |
PLATE
|
PLO
|
| 3. |
120245
|
[4] |
CARRIAGE BOLT,Short Sq Nk, M10 x 30mm, Cl 8.8, Full Thd
|
ZED
M10x30 Superseded by part number: 86512446
|
| 4. |
80140028
|
[4] |
SPRING WASHER
|
ZED
10MM Superseded by part number: 140028
|
| 5. |
100016
|
[8] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 6. |
84024166
|
[1] |
PLATE
|
PLO
|
| 7. |
80120068
|
[4] |
SCREW
|
ZED
M10x40 Superseded by part number: 120068
|
| 8. |
80140045
|
[10] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 9. |
80120201
|
[4] |
BOLT
|
ZED
M10x35 Superseded by part number: 9706704
|
| 10. |
86514720
|
[4] |
NUT
|
WIN
M10 Superseded by part number: 190003888452
|
| 11. |
84822362
|
[1] |
PLATE
|
PLO
|
| 12. |
84822369
|
[1] |
HINGE
|
PLO
|
| 13. |
84024535
|
[1] |
SHAFT
|
PLO
|
| 14. |
80130006
|
[2] |
COTTER PIN
|
ZED
Superseded by part number: 130006
|
| 15. |
84822363
|
[1] |
SUPPORT
|
PLO
|
| 16. |
80322358
|
[9] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 17. |
120104
|
[9] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 18. |
84822360
|
[1] |
SUPPORT
|
PLO
|
| 19. |
80120109
|
[2] |
SCREW
|
ZED
M10x20 Superseded by part number: 43138
|
