凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (13.08[01]) - FEEDER AND CROPCUTTER ASSEMBLY, FRAME Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
786 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84025765
|
[1] |
RAKE
|
PLO
|
| 2. |
84058162
|
[1] |
PLATE
|
PLO
|
| 3. |
84024436
|
[1] |
ADJUSTING PLATE
|
PLO
|
| 4. |
84822374
|
[1] |
PLATE
|
PLO
, Serial Range: -C667 Superseded by part number: 84820201
|
| 4. |
84820201
|
[1] |
PLATE
|
PLO
, Start Serial: D668
|
| 5. |
80120109
|
[17] |
SCREW
|
ZED
M10x20 Superseded by part number: 43138
|
| 6. |
80140045
|
[1] |
WASHER
|
ZED
10MM Superseded by part number: 140045
|
| 7. |
80120031
|
[1] |
SCREW,M6 x 16mm
|
ZED
M6x16 Superseded by part number: 86512439
|
| 8. |
80120111
|
[14] |
SCREW
|
ZED
M10x30 Superseded by part number: 43140
|
| 9. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
84822366
|
[1] |
COVER PLATE
|
PLO
, Serial Range: -C667 Superseded by part number: 84820200
|
| 10. |
84820200
|
[1] |
COVER PLATE
|
PLO
, Start Serial: D668
|
| 11. |
86514720
|
[1] |
NUT
|
WIN
M10 Superseded by part number: 190003888452
|
| 12. |
43362
|
[2] |
NUT,M8 x 1.25, Cl 10
|
BHB
|
| 13. |
80322358
|
[2] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 14. |
84025014
|
[1] |
GUIDE
|
PLO
|
| 15. |
120191
|
[2] |
CARRIAGE BOLT,Short Sq Nk, M8 x 40mm, Cl 8.8, Full Thd
|
PA
M8x40 Superseded by part number: 86512444
|
| 16. |
84054218
|
[1] |
CANVAS,1368mm L
|
PLO
|
| 17. |
84025094
|
[1] |
COVER PLATE
|
PLO
|
| 18. |
80043139
|
[8] |
BOLT,M10 x 25mm
|
ZED
Superseded by part number: 11106231
|
| 19. |
15896221
|
[1] |
NUT,Hex, M6, 5.20mm High, Cl 10
|
ZED
Superseded by part number: 86500688
|
| 20. |
80322357
|
[1] |
LOCK WASHER,Belleville, M6
|
ZED
6MM Superseded by part number: 322357
|
