凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (13.14[01]) - CROPCUTTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
821 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 2. |
80450876
|
[1] |
EYEBOLT
|
PLO
Superseded by part number: 450876
|
| 3. |
84024212
|
[1] |
SPRING
|
PLO
|
| 4. |
80393871
|
[1] |
LOCK PIN
|
ZED
5x30 Superseded by part number: 393871
|
| 5. |
84024231
|
[1] |
HANDLE
|
PLO
|
| 6. |
84024277
|
[1] |
SPRING
|
PLO
|
| 7. |
80370003
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 370003
|
| 8. |
80370007
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 370007
|
| 9. |
80378087
|
[1] |
RING,45mm ID x 65mm OD x 1.25mm Thk
|
ZED
|
| 10. |
80100038
|
[1] |
NUT
|
ZED
Superseded by part number: 100038
|
| 11. |
80350341
|
[1] |
STUD
|
ZED
Superseded by part number: 350341
|
| 12. |
337475
|
[1] |
NUT,M12, Cl 10
|
BHB
|
| 13. |
84024229
|
[1] |
ARM
|
PLO
|
| 14. |
84025877
|
[1] |
BOLT,Hex, M12 x 70mm, Cl 8.8, Full Thd
|
PLO
M12x70
|
| 15. |
84024233
|
[1] |
GUIDE PIN
|
PLO
|
| 16. |
84024319
|
[1] |
HUB
|
PLO
|
| 17. |
84025499
|
[6] |
WASHER
|
ZED
|
| 18. |
84790078
|
[1] |
PLATE
|
PLO
, Start Serial: D640
|
| 19. |
86624468
|
[1] |
SPACER,1.65" L x 5/16” Thk
|
NH
, Start Serial: D640
|
| 20. |
86594422
|
[1] |
SENSOR
|
NH
, Start Serial: D640
|
| 21. |
80043127
|
[2] |
SCREW,M8 x 25mm
|
ZED
M8x25, Start Serial: D640 Superseded by part number: 43127
|
| 22. |
80322358
|
[4] |
LOCK WASHER
|
ZED
8MM, Start Serial: D640 Superseded by part number: 322358
|
| 24. |
86900322
|
[2] |
SCREW,Phillips Drive, Truss HD, #10 - 24 x 1-1/4", SST
|
PA
, Start Serial: D640
|
| 25. |
86900323
|
[2] |
NUT,#10 - 24
|
PA
, Start Serial: D640
|
| 23. |
89706690
|
[2] |
NUT,M8, Cl 8
|
ZED
, Start Serial: D640 Superseded by part number: 43362
|
