凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (14.03[01]) - FLOOR ROLL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
717 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
89706694
|
[2] |
NUT,M20, Cl 8
|
ZED
Superseded by part number: 9706694
|
| 2. |
80322359
|
[2] |
LOCK WASHER
|
ZED
20MM Superseded by part number: 322359
|
| 3. |
80139056
|
[2] |
WASHER
|
PLO
Superseded by part number: 139056
|
| 4. |
84429279
|
[2] |
COVER PLATE
|
PLO
|
| 5. |
80120044
|
[4] |
BOLT
|
ZED
M12x30 Superseded by part number: 120044
|
| 6. |
86511324
|
[8] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 7. |
120084
|
[8] |
BOLT,Hex, M12 x 80, 8.8
|
PA
Superseded by part number: 43158
|
| 8. |
80140046
|
[16] |
WASHER
|
ZED
12MM Superseded by part number: 140046
|
| 9. |
84024200
|
[1] |
DRIVEN SPROCKET
|
PLO
|
| 10. |
84024891
|
[2] |
BEARING HOUSING
|
PLO
|
| 11. |
84024288
|
[1] |
COVER
|
PLO
|
| 12. |
84024167
|
[4] |
FLANGE
|
PLO
|
| 13. |
80455805
|
[2] |
BEARING ASSY
|
ZED
Superseded by part number: 84057307, 563733
|
| 14. |
80120120
|
[8] |
SCREW
|
ZED
M12X30 Superseded by part number: 9706687
|
| 15. |
84024286
|
[1] |
SHAFT
|
PLO
|
| 16. |
84024265
|
[1] |
ROLLER
|
PLO
|
| 17. |
84025767
|
[1] |
CHAIN,60 HV, 90 Links x 19.05mm = 1714.5mm
|
PLO
(18,19)
|
| 18. |
89811889
|
[1] |
CONNECTING LINK
|
PLO
Superseded by part number: 9811889
|
| 19. |
89811888
|
[1] |
LINK CHAIN
|
ZED
Superseded by part number: 9811888
|
| 20. |
84822327
|
[1] |
SHIELD
|
PLO
, Serial Range: -C667
|
| 20. |
84820706
|
[1] |
SHIELD
|
PLO
, Start Serial: D668
|
| 21. |
84024237
|
[1] |
DRIVEN SPROCKET
|
PLO
|
| 22. |
80170019
|
[1] |
KEY
|
ZED
Superseded by part number: 170019
|
| 23. |
80300489
|
[1] |
SCREW
|
PLO
M12x25 Superseded by part number: 300489
|
| 24. |
337475
|
[1] |
NUT,M12, Cl 10
|
BHB
|
