凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (14.04[01]) - IDLER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
685 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 2. |
84025887
|
[1] |
EYEBOLT
|
PLO
|
| 3. |
80056686
|
[1] |
SPRING
|
PLO
Superseded by part number: 56686
|
| 4. |
84024221
|
[1] |
DRIVEN SPROCKET
|
PLO
|
| 5. |
80120090
|
[1] |
SCREW
|
ZED
M16x50 Superseded by part number: 120090
|
| 6. |
80100039
|
[1] |
NUT
|
ZED
M16 Superseded by part number: 86000441
|
| 7. |
84024582
|
[2] |
BUSHING
|
PLO
|
| 8. |
84025722
|
[1] |
VOLTAGE REGULATOR
|
PLO
|
| 9. |
80140229
|
[1] |
WASHER
|
ZED
Superseded by part number: 140229
|
| 10. |
80140104
|
[1] |
WASHER
|
ZED
Superseded by part number: 140104
|
| 11. |
80370002
|
[1] |
CIRCLIP
|
ZED
Superseded by part number: 370002
|
