凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (15.24A[01]) - SATELLITE - ENGINE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
284 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84821095
|
[1] |
HYDRAULIC MOTOR
|
PLO
, Serial Range: (2-12)
|
| 2. |
84819482
|
[1] |
FLANGE
|
PLO
|
| 3. |
84819483
|
[1] |
BEARING WASHER
|
PLO
|
| 4. |
84819484
|
[1] |
NEEDLE BEARING
|
PLO
|
| 5. |
84819485
|
[2] |
CHECK VALVE
|
PLO
|
| 6. |
84819486
|
[12] |
NOTCHED DISK
|
PLO
|
| 7. |
84819487
|
[11] |
BRAKE DISC
|
PLO
|
| 8. |
84819488
|
[1] |
PAD
|
PLO
Superseded by part number: 221659A1
|
| 9. |
84819489
|
[1] |
PISTON
|
PLO
Superseded by part number: 221660A1
|
| 10. |
84819490
|
[7] |
SPRING
|
PLO
|
| 11. |
84819491
|
[7] |
SPRING
|
PLO
|
| 12. |
84819481
|
[7] |
SEAL KIT
|
PLO
|
