凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (15.25[01]) - SATELLITE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
111 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84820563
|
[2] |
ARM
|
PLO
|
| 2. |
84821160
|
[2] |
ARM
|
PLO
|
| 3. |
89838862
|
[2] |
SPRING
|
ZED
Superseded by part number: 9838862
|
| 4. |
86562594
|
[2] |
BOLT,Hex, M12 x 110mm, Cl 8.8
|
NH
|
| 5. |
80100038
|
[2] |
NUT
|
ZED
12MM Superseded by part number: 100038
|
| 6. |
86511324
|
[2] |
WASHER,13mm ID x 24mm OD x 2.5mm Thk
|
NH
Superseded by part number: 87364
|
| 7. |
84820180
|
[1] |
SHIM
|
PLO
|
| 8. |
84000555
|
[2] |
INSULATOR,Bumper
|
ZED
|
| 9. |
86511315
|
[2] |
WASHER,8.4mm ID x 16mm OD x 1.8mm Thk
|
NH
Superseded by part number: 86624184
|
| 11. |
120104
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 12. |
80322358
|
[8] |
LOCK WASHER
|
ZED
8MM Superseded by part number: 322358
|
| 10. |
89706690
|
[2] |
NUT,M8, Cl 8
|
ZED
Superseded by part number: 43362
|
