凯斯零件查询(RBX341) - SILAGE PACK ROUND BALER (3/03-12/05) (15.27[01]) - PRE-STRETCHERS - C651 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
229 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84822545
|
[1] |
KIT
|
PLO
, Serial Range: (2-50) Superseded by part number: 84800215
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
|
| 5. |
84819536
|
[2] |
BEARING ASSY
|
PLO
Superseded by part number: ST544
|
| 6. |
84819537
|
[1] |
CIRCLIP
|
PLO
|
| 8. |
84819518
|
[1] |
LOCK
|
PLO
|
| 9. |
84819521
|
[1] |
SPRING
|
PLO
|
| 10. |
84819520
|
[1] |
SHAFT
|
PLO
|
| 11. |
84819533
|
[1] |
KNOB
|
PLO
|
| 12. |
84819542
|
[1] |
LOCK SCREW
|
PLO
|
| 13. |
84819524
|
[2] |
CIRCLIP
|
PLO
|
| 16. |
84819522
|
[1] |
GUIDE
|
PLO
|
| 17. |
84819543
|
[1] |
CAP
|
PLO
|
| 21. |
84819535
|
[4] |
SLEEVE
|
PLO
|
| 22. |
84819531
|
[2] |
SPRING
|
PLO
|
| 23. |
84819528
|
[1] |
ARM
|
PLO
|
| 26. |
84819527
|
[2] |
SHAFT
|
PLO
|
| 27. |
84819526
|
[4] |
CIRCLIP
|
PLO
|
| 28. |
84819539
|
[4] |
CIRCLIP
|
PLO
|
| 29. |
84819538
|
[4] |
WASHER
|
PLO
|
| 30. |
84819517
|
[4] |
BEARING ASSY
|
PLO
|
| 31. |
84801079
|
[4] |
O-RING
|
PLO
Superseded by part number: 84819517
|
| 32. |
84819523
|
[2] |
ROLLER
|
PLO
|
| 34. |
84819515
|
[1] |
GEAR
|
PLO
Z=18
|
| 35. |
84819519
|
[1] |
GEAR
|
PLO
Z=30
|
| 37. |
84819514
|
[1] |
ARM
|
PLO
|
| 38. |
84819516
|
[2] |
CAP
|
PLO
|
| 40. |
84819534
|
[1] |
SHAFT
|
PLO
|
| 41. |
84819530
|
[4] |
SLEEVE
|
PLO
|
| 42. |
84819529
|
[2] |
RING
|
PLO
|
| 43. |
84819532
|
[2] |
PIN
|
PLO
|
| 45. |
84819541
|
[2] |
LOCKING PLATE
|
PLO
|
| 46. |
84819540
|
[2] |
BRACKET
|
PLO
|
| 50. |
84819525
|
[1] |
SUPPORT
|
PLO
|
