斗山零件查询OIL COOLER PIPING(1) DX360LCA(S/N:5950~) Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
681 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
420212-04795
|
[-] |
|
|
| 1. |
K1004777C
|
[1] |
PIPE;SUCTION
|
|
| 1. |
420218-00505
|
[1] |
|
420218-00505A
|
| 1. |
420218-00505A
|
[1] |
|
|
| 146. |
2181-1950D9
|
[1] |
PLUG
|
|
| 147. |
S8000291
|
[1] |
O-RING
|
|
| 25. |
2181-1126D6
|
[2] |
ADAPTER
|
|
| 26. |
DS2380004
|
[1] |
ADAPTER;FILTER
|
|
| 27. |
2181-2627D1
|
[2] |
ADAPTER
|
|
| 31. |
S2221566
|
[4] |
BOLT
|
|
| 34. |
DS2055854
|
[1] |
HOSE
|
|
| 35. |
DS2012245
|
[1] |
HOSE
|
|
| 38. |
DS2055304
|
[1] |
HOSE
|
|
| 39. |
S8500143
|
[4] |
CLAMP;HOSE
|
|
| 43. |
2180-1026D35
|
[1] |
O-RING
|
|
| 44. |
S8040081
|
[1] |
O-RING
|
|
| 45. |
2181-2419D3
|
[1] |
ELBOW
|
|
| 46. |
S8000181
|
[3] |
O-RING
|
|
| 47. |
S8030121
|
[2] |
O-RING
|
|
| 48. |
S8000231
|
[2] |
O-RING
|
|
| 6. |
DS2086015
|
[1] |
|
|
