沃尔沃零件查询D16C-D MHEngineFlywheel HousingEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
484 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3886300
|
[1] |
Flywheel housing
|
Replaced by 22569116 SN-1016095824
|
| 1. |
22569116
|
[1] |
Flywheel housing
|
SN1016095825-
|
| 2. |
85108352
|
[1] |
Crankshaft seal
|
|
| 3. |
984738
|
[4] |
Flange screw
|
L=40mm
|
| 3. |
984740
|
[1] |
Flange screw
|
L=60mm
|
| 4. |
984760
|
[5] |
Flange screw
|
M10x90mm
|
| 4. |
984862
|
[6] |
Flange screw
|
M14x90mm
|
| 4. |
984863
|
[1] |
Flange screw
|
M14x100mm
|
| 5. |
22199951
|
[1] |
Timing gear cover
|
SN-2016007731
|
| 5. |
22997662
|
[1] |
Timing gear cover
|
SN2016007732-
|
| 6. |
20815558
|
[1] |
Sealing strip
|
(20747434)
|
| 7. |
21185132
|
[2] |
Seal
|
|
| 8. |
1161277
|
[1] |
Sealant
|
20g
|
| 9. |
15134976
|
[1] |
Plug
|
|
| 10. |
849405
|
[1] |
Setting indicator
|
|
| 11. |
950893
|
[2] |
Drive screw
|
|
| 12. |
4772168
|
[1] |
Cover
|
|
| 13. |
984726
|
[2] |
Flange screw
|
|
| 14. |
4804167
|
[1] |
Gasket
|
|
| 15. |
984813
|
[3] |
Flange screw
|
|
| 16. |
849135
|
[1] |
Cover
|
|
| 17. |
942315
|
[1] |
Hose nipple
|
|
| 18. |
|
|
|
|
| 19. |
|
|
|
|
| 20. |
975110
|
[8] |
Flange screw
|
|
| 21. |
984755
|
[4] |
Flange screw
|
|
