纽荷兰零件查询(DC150LT) - CRAWLER DOZER (6/00-) (5.601[03]) - HOODS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
279 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76069313 | [1] | COWLING | TOR- ASSY |
| 2. | 76066351 | [1] | LID | LEC |
| 3. | 79109730 | [4] | RUBBER BUSHING | LEC |
| 4. | 79109731 | [2] | SPACER | LEC |
| 5. | 11113831 | [2] | SCREW,Hex, M12 x 80mm, Cl 10.9 | LEC Superseded by part number: 11113821, 412085 |
| 6. | 14508287 | [4] | PLUG | LECB-50 |
| 7. | 76054691 | [2] | SEAL | LEC Superseded by part number: 93201838 |
| 8. | 14496531 | [4] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 9. | 16043231 | [4] | SCREW,Hex, M8 x 16mm, Cl 10.9, Full Thd | LEC |
| 10. | 12648531 | [4] | WASHER,12.2mm ID x 28mm OD x 4mm Thk | LEC Superseded by part number: 86625256 |
| 11. | 76066371 | [1] | LOCK | LEC- ASSY SEE TAV.6 |
| 12. | 11112831 | [2] | SCREW,Hex, M12 x 40mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11125434 |
| 13. | 79032003 | [2] | BUSHING | LEC |
| 14. | 79109732 | [1] | WASHER,M12.5 x 43 x 3 Thk | LEC |
| 15. | 14496731 | [2] | WASHER,M12 x 24 x 2.5 Thk | LEC Superseded by part number: 895-11012 |
| 16. | 76066137 | [4] | HINGE | LEC |
| 17. | 12645031 | [12] | WASHER,8.45mm ID x 21mm OD x 3mm Thk | LEC |
| 18. | 16043531 | [12] | SCREW,Hex, M8 x 1.25 x 22mm, Cl 10.9, Full Thd | LEC |
| 19. | 10615679 | [4] | LOCK WASHER,Ext Tooth, M8 | BHB8 Superseded by part number: 10615671 |
