| 1. |
87037949
|
[1] |
SHIELD
|
PA
Includes: Ref. 31
|
| 1. |
87028217
|
[1] |
SHIELD
|
NH
Superseded by part number: 87037949
|
| 2. |
86636403
|
[1] |
MOUNTING PARTS
|
PA
Includes: Ref. 3
|
| 3. |
86643977
|
[3] |
ANTI-SKID STRIP,4” x 40”, Black
|
NH
|
| 4. |
86631554
|
[1] |
CHANNEL
|
NH
|
| 5. |
86631522
|
[1] |
SHEET METAL
|
NH
Stuffer Tool Superseded by part number: 87026611
|
| 6. |
87014357
|
[1] |
DOOR ASSY.
|
NH
Net, Includes: Decals
|
| 6. |
86631676
|
[1] |
DOOR ASSY.
|
NH
Net Superseded by part number: 87014357
|
| 7. |
86636528
|
[1] |
BRACKET
|
NH
Superseded by part number: 87015063
|
| 8. |
86632759
|
[1] |
SHIELD
|
NH
|
| 9. |
86642356
|
[1] |
DECAL
|
PA
|
| 10. |
844-6016
|
[6] |
BOLT,Hvy Hex, M6 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 9804255
|
| 11. |
87017062
|
[1] |
FLOOR
|
PA
|
| 13. |
86507486
|
[9] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 14. |
811-6016
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 16mm, Cl 8.8
|
CAS
Superseded by part number: 86512439
|
| 15. |
811-10030
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 16. |
844-8020
|
[9] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 17. |
614-8020
|
[4] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 18. |
322357
|
[10] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 19. |
322358
|
[17] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 20. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 21. |
140046
|
[2] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 22. |
86626584
|
[2] |
BRACKET
|
PA
|
| 23. |
495-21038
|
[9] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| 24. |
825-2406
|
[8] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 25. |
825-2408
|
[15] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 26. |
825-2410
|
[2] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 27. |
825-1412
|
[2] |
NUT,M12, Cl 8
|
CAS
Superseded by part number: 9706685
|
| 28. |
87018459
|
[1] |
SHIELD,318mm W x 1176mm L x 3.175mm Thk, Rubber
|
PA
|
| 29. |
87019330
|
[1] |
RUBBER SEAL
|
PA
|
| 30. |
832-46408
|
[7] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 31. |
87037375
|
[1] |
WARNING DECAL
|
PA
Net Knife, English
|
| 31. |
87037730
|
[1] |
DECAL
|
PA
WARNING, Net Knife, French
|
| 32. |
86610198
|
[2] |
INSERT,M6 x 1
|
NH
Threaded, M6
|
| 33. |
86610200
|
[2] |
THREADED INSERT,M8 x 1.25
|
NH
M8
|
