纽荷兰零件查询(DC150LT) - CRAWLER DOZER (6/00-) (3.437[01]) - CONTROL VALVE LINKAGE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
248 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76046930 | [1] | PLATE | TOR |
| 2. | 14163871 | [1] | ROLL PIN | LEC4X18 Superseded by part number: 14163870 |
| 3. | 76046726 | [1] | BUSHING | TOR |
| 4. | 79084568 | [2] | BEARING ASSY,Needle, 16mm ID x 22mm OD x 14mm W | LEC |
| 5. | 14164771 | [1] | ROLL PIN | MKT4X40 Superseded by part number: 14164770 |
| 5. | 11106431 | [1] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 9515003 |
| 6. | 76046929 | [1] | PIN | TOR |
| 7. | 76046733 | [4] | PIN | TOR |
| 8. | 76046730 | [4] | TIE-ROD | TOR |
| 9. | 76046931 | [1] | PIN | TOR |
| 10. | 10734101 | [1] | COTTER PIN,M1.6 x 12 | BAS Superseded by part number: 87016658 |
| 11. | 76046924 | [1] | LEVER | TOR- ASSY |
| 14. | 11701721 | [7] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 15. | 76054501 | [1] | QUICK MALE COUPLING | TOR- ASSY |
| 16. | 76054502 | [1] | TIE-ROD | TOR |
| 17. | 14496431 | [1] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 18. | 10802801 | [4] | COTTER PIN,M2.5 x 25 | LEC |
| 19. | 79092808 | [2] | ARTICULATION | LEC |
| 20. | 76046993 | [2] | THREADED TIE-ROD | TOR |
| 21. | 76046926 | [1] | LEVER | TOR- ASSY |
| 22. | 79083370 | [2] | QUICK MALE COUPLING | LEC- ASSY |
| 23. | 13420776 | [1] | RING | LEC |
| 24. | 79086837 | [1] | SPRING | LEC |
