| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 01. | Y700818 | [1] | BRACKET | |
| 02. | J021035 | [4] | BOLT;SEMS | |
| 04. | 88-0116 | [1] | MOTOR | REXROTH A2FM10/61W-PPB03 |
| 05. | J010830 | [4] | BOLT;SEMS | |
| 06. | Y410206 | [1] | PLATE | |
| 07. | J901245 | [3] | BOLT | |
| 08. | A590912 | [3] | WASHER;SPRING | |
| 09. | A590112 | [3] | WASHER;PLANE | |
| 10. | J950012 | [3] | NUT | |
| 12. | Y410200 | [1] | BELT PULLEY | |
| 13. | Y410214 | [3] | SCREW;SET | |
| 14. | Y410202 | [1] | STOPPER | |
| 15. | J780616 | [1] | BOLT;SOCKET | |
| 16. | Y410333 | [1] | CONNECTOR | |
| 17. | A852123 | [1] | ADAPTER;S | |
| 18. | Y411017 | [1] | PLUG | |
| 19. | 88-XXXX | [2] | ELBOW | PARKER 12M22C80MXS |
| 22. | Y410207 | [1] | BRACKET | |
| 23. | J900620 | [4] | BOLT | |
| 24. | A590906 | [8] | WASHER;SPRING | |
| 25. | A590106 | [4] | WASHER;PLANE | |
| 26. | M500605 | [4] | NUT | |
| 28. | Y410205 | [1] | DRIVE WHEEL | |
| 29. | Y410215 | [1] | SCREW;SET | |
| 31. | 88-0263 | [1] | PUMP | VIKING PUMP GX2-115 |
| 32. | J900630 | [4] | BOLT | |
| 35. | Y410199 | [1] | BELT PULLEY | |
| 36. | Y410204 | [1] | COUPLING | |
| 37. | J780830 | [3] | BOLT;SOCKET | |
| 38. | Y410201 | [1] | DRIVE WHEEL | |
| 40. | Y410203 | [1] | BRG. | |
| 41. | Y410210 | [3] | SPACER | |
| 42. | Y410211 | [3] | SPACER | |
| 43. | Y410212 | [3] | SPACER | |
| 44. | J021040 | [2] | BOLT;SEMS | |
| 45. | Y410991 | [1] | SPACER | |
| 46. | Y410209 | [1] | DRIVING BELT | |
| 47. | Y410208 | [1] | DRIVING BELT | |
| 49. | Y971069 | [1] | GUARD | |
| 50. | J900816 | [5] | BOLT | |
| 51. | A590908 | [5] | WASHER;SPRING | |
| 52. | Y410342 | [1] | KEY | |
| 53. | Y411791 | [1] | ENCODER | |
| 54. | Y410500 | [1] | HOUSING | |
| 55. | M430420 | [4] | SCREW | |
| 56. | A590104 | [4] | WASHER;PLANE | |
| 57. | A590904 | [4] | WASHER;SPRING | |
| 58. | M500403 | [4] | NUT | |
| 59. | J75481 | [1] | FITTING;GREASE | |
| 60. | Y410499 | [1] | BRACKET | |
| 63. | M500807 | [1] | NUT | |
| 64. | Y410512 | [1] | BRG. | |
| 65. | Z443964 | [1] | RING;RETAINING | |
| 66. | Y410501 | [1] | SHAFT | |
| 67. | Y410513 | [1] | RING;RETAINING |
