纽荷兰零件查询(DC150LT) - CRAWLER DOZER (6/00-) (9.440[05]) - FRONT IMPLEMENT ALL HYDR.- HYDR. SYSTEM - OPTIONAL CODE 76054902 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
601 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76054867 | [1] | FLEXIBLE HOSE | TOR |
| 2. | 76054868 | [1] | FLEXIBLE HOSE | TOR |
| 3. | 70923841 | [4] | O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro | LEC Superseded by part number: 9992298 |
| 5. | 14496631 | [3] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
| 6. | 76041055 | [1] | COLLAR CLAMP | LEC |
| 7. | 11106631 | [1] | SCREW,Hex, M10 x 35mm, Cl 10.9, Full Thd | LEC Superseded by part number: 86624978 |
| 9. | 79076680 | [1] | CLAMP | LEC |
| 10. | 16040831 | [1] | BOLT,Hex, M10 x 1.5 x 40mm, Cl 10.9, Full Thd | LEC Superseded by part number: 43248 |
| 11. | 12626231 | [1] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
